Hitachi RAS-5FSNY2E [81/148] Ras 5fsvn2e
![Hitachi RAS-5FSNY2E [81/148] Ras 5fsvn2e](/views2/1321845/page81/bg51.png)
4 Capacities and
selection data
73
TCGB0068 rev.1 - 08/2012
4
RAS-5FSVN2E
To
Total power of combined indoor units (50%) Total power of combined indoor units (60%)
Ti Ti
16 18 20 22 24 16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
4.72 1.63 4.56 1.71 4.56 1.79 4.48 1.87 4.40 1.96 5.66 1.94 5.47 2.03 5.47 2.13 5.38 2.22 5.28 2.33
-17
4.86 1.65 4.75 1.72 4.70 1.80 4.62 1.89 4.59 1.97 5.84 1.96 5.70 2.04 5.64 2.14 5.55 2.24 5.51 2.34
-15
4.96 1.66 4.88 1.73 4.80 1.82 4.72 1.90 4.72 1.99 5.95 1.97 5.86 2.06 5.76 2.16 5.66 2.26 5.66 2.36
-13
5.15 1.68 5.07 1.75 4.99 1.83 4.91 1.91 4.91 2.00 6.18 1.99 6.09 2.08 5.99 2.18 5.89 2.27 5.89 2.38
-11
5.34 1.69 5.26 1.76 5.18 1.85 5.10 1.93 5.10 2.02 6.41 2.01 6.32 2.09 6.22 2.19 6.12 2.29 6.12 2.39
-10
5.44 1.70 5.36 1.78 5.28 1.86 5.20 1.94 5.20 2.03 6.53 2.02 6.43 2.11 6.34 2.21 6.24 2.31 6.24 2.41
-9
5.57 1.72 5.49 1.79 5.42 1.87 5.36 1.96 5.36 2.04 6.68 2.04 6.59 2.13 6.51 2.23 6.43 2.32 6.43 2.43
-7
5.82 1.73 5.74 1.81 5.71 1.89 5.68 1.97 5.68 2.06 6.99 2.06 6.89 2.14 6.85 2.24 6.82 2.34 6.82 2.44
-6
5.95 1.75 5.87 1.82 5.86 1.90 5.84 1.98 5.84 2.07 7.14 2.07 7.05 2.16 7.03 2.26 7.01 2.36 7.01 2.46
-5
6.08 1.76 6.00 1.83 6.00 1.92 6.00 2.00 6.00 2.09 7.30 2.09 7.20 2.18 7.20 2.28 7.20 2.37 7.20 2.48
-3
6.43 1.78 6.38 1.85 6.35 1.93 6.35 2.01 6.32 2.10 7.72 2.11 7.66 2.19 7.62 2.29 7.62 2.39 7.58 2.49
-1
6.78 1.79 6.77 1.86 6.70 1.95 6.70 2.03 6.64 2.12 8.14 2.12 8.12 2.21 8.04 2.31 8.04 2.41 7.97 2.51
0
6.96 1.80 6.96 1.88 6.88 1.96 6.88 2.04 6.80 2.13 8.35 2.14 8.35 2.23 8.26 2.33 8.26 2.42 8.16 2.53
1
7.15 1.82 7.15 1.89 7.07 1.97 7.06 2.05 6.98 2.14 8.58 2.16 8.58 2.24 8.49 2.34 8.47 2.44 8.37 2.55
3
7.54 1.83 7.54 1.90 7.46 1.99 7.41 2.07 7.33 2.16 9.04 2.18 9.04 2.26 8.95 2.36 8.89 2.46 8.79 2.56
5
7.92 1.85 7.92 1.92 7.84 2.00 7.76 2.08 7.68 2.17 9.50 2.19 9.50 2.28 9.41 2.38 9.31 2.47 9.22 2.58
6
8.16 1.86 8.08 1.93 8.00 2.02 7.92 2.10 7.84 2.19 9.79 2.21 9.70 2.29 9.60 2.39 9.50 2.49 9.41 2.60
7
8.34 1.87 8.24 1.95 8.18 2.03 8.10 2.11 8.00 2.20 10.01 2.23 9.89 2.31 9.82 2.41 9.72 2.51 9.60 2.61
9
8.70 1.89 8.56 1.96 8.54 2.04 8.46 2.12 8.32 2.21 10.44 2.24 10.27 2.33 10.25 2.43 10.15 2.52 9.98 2.63
10
8.88 1.90 8.72 1.97 8.72 2.06 8.64 2.14 8.48 2.23 10.66 2.26 10.46 2.35 10.46 2.44 10.37 2.54 10.18 2.65
11
8.94 1.92 8.78 1.99 8.77 2.07 8.69 2.15 8.53 2.24 10.73 2.28 10.54 2.36 10.52 2.46 10.43 2.56 10.23 2.66
14
9.14 1.93 8.98 2.00 8.91 2.09 8.83 2.17 8.67 2.26 10.96 2.29 10.77 2.38 10.69 2.48 10.60 2.57 10.41 2.68
15
9.20 1.94 9.04 2.02 8.96 2.10 8.88 2.18 8.72 2.27 11.04 2.31 10.85 2.40 10.75 2.49 10.66 2.59 10.46 2.70
To
Total power of combined indoor units (70%) Total power of combined indoor units (80%)
Ti Ti
16 18 20 22 24 16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
6.61 2.25 6.38 2.35 6.38 2.46 6.27 2.57 6.16 2.69 7.55 2.62 7.30 2.74 7.30 2.87 7.17 3.00 7.04 3.14
-17
6.81 2.27 6.65 2.37 6.59 2.48 6.47 2.59 6.43 2.71 7.78 2.64 7.60 2.76 7.53 2.89 7.40 3.02 7.35 3.17
-15
6.94 2.29 6.83 2.39 6.72 2.50 6.61 2.61 6.61 2.73 7.94 2.67 7.81 2.78 7.68 2.92 7.55 3.05 7.55 3.19
-13
7.21 2.31 7.10 2.40 6.99 2.52 6.88 2.63 6.88 2.75 8.24 2.69 8.12 2.81 7.99 2.94 7.86 3.07 7.86 3.21
-11
7.48 2.32 7.37 2.42 7.26 2.54 7.15 2.65 7.15 2.77 8.55 2.71 8.42 2.83 8.29 2.96 8.17 3.09 8.17 3.23
-10
7.62 2.34 7.50 2.44 7.39 2.56 7.28 2.67 7.28 2.79 8.70 2.73 8.58 2.85 8.45 2.98 8.32 3.11 8.32 3.26
-9
7.80 2.36 7.68 2.46 7.59 2.58 7.50 2.69 7.50 2.81 8.91 2.76 8.78 2.87 8.68 3.01 8.58 3.14 8.58 3.28
-7
8.15 2.38 8.04 2.48 8.00 2.60 7.95 2.71 7.95 2.83 9.32 2.78 9.19 2.90 9.14 3.03 9.09 3.16 9.09 3.30
-6
8.33 2.40 8.22 2.50 8.20 2.62 8.18 2.73 8.18 2.85 9.52 2.80 9.40 2.92 9.37 3.05 9.34 3.18 9.34 3.32
-5
8.51 2.42 8.40 2.52 8.40 2.64 8.40 2.75 8.40 2.87 9.73 2.83 9.60 2.94 9.60 3.08 9.60 3.21 9.60 3.35
-3
9.00 2.44 8.94 2.54 8.89 2.66 8.89 2.77 8.85 2.89 10.29 2.85 10.21 2.96 10.16 3.10 10.16 3.23 10.11 3.37
-1
9.50 2.46 9.48 2.56 9.39 2.67 9.39 2.79 9.30 2.91 10.85 2.87 10.83 2.99 10.73 3.12 10.73 3.25 10.62 3.39
0
9.74 2.48 9.74 2.58 9.63 2.69 9.63 2.81 9.52 2.93 11.14 2.89 11.14 3.01 11.01 3.14 11.01 3.27 10.88 3.42
1
10.01 2.50 10.01 2.60 9.90 2.71 9.88 2.82 9.77 2.95 11.44 2.92 11.44 3.03 11.32 3.17 11.29 3.30 11.16 3.44
3
10.55 2.52 10.55 2.62 10.44 2.73 10.37 2.84 10.26 2.97 12.06 2.94 12.06 3.05 11.93 3.19 11.85 3.32 11.72 3.46
5
11.09 2.54 11.09 2.64 10.98 2.75 10.86 2.86 10.75 2.99 12.67 2.96 12.67 3.08 12.54 3.21 12.42 3.34 12.29 3.48
6
11.42 2.56 11.31 2.66 11.20 2.77 11.09 2.88 10.98 3.01 13.06 2.98 12.93 3.10 12.80 3.23 12.67 3.36 12.54 3.51
7
11.68 2.58 11.54 2.68 11.45 2.79 11.34 2.90 11.20 3.02 13.34 3.01 13.18 3.12 13.09 3.26 12.96 3.39 12.80 3.53
9
12.18 2.60 11.98 2.70 11.96 2.81 11.84 2.92 11.65 3.04 13.92 3.03 13.70 3.15 13.66 3.28 13.54 3.41 13.31 3.55
10
12.43 2.62 12.21 2.72 12.21 2.83 12.10 2.94 11.87 3.06 14.21 3.05 13.95 3.17 13.95 3.30 13.82 3.43 13.57 3.57
11
12.52 2.63 12.30 2.73 12.28 2.85 12.16 2.96 11.94 3.08 14.31 3.07 14.05 3.19 14.03 3.32 13.90 3.45 13.64 3.60
14
12.79 2.65 12.57 2.75 12.48 2.87 12.36 2.98 12.14 3.10 14.62 3.10 14.36 3.21 14.26 3.35 14.13 3.48 13.88 3.62
15
12.88 2.67 12.66 2.77 12.54 2.89 12.43 3.00 12.21 3.12 14.72 3.12 14.46 3.24 14.34 3.37 14.21 3.50 13.95 3.64
