3 General data
35
TCGB0068 rev.1 - 08/2012
3
3.1.2 RAS-4FS(V)N(Y)2E
Item Units RAS-4FSVN2E RAS-4FSNY2E
Minimum - Maximum indoor units connectable - 1 - 8 (*1) 1 - 8 (*1)
Minimum - Maximum connected capacity % 50 - 130 50 - 130
Nominal cooling capacity (min - max) kW 11.2 (5.60 - 11.2) 11.2 (5.60 - 11.2)
Nominal heating capacity (min - max) kW 12.5 (6.30 - 12.5) 12.5 (6.30 - 12.5)
Nominal cooling power input kW 2.75 2.72
Nominal heating power input kW 3.03 3.00
EER / COP (*2) - 4.07 / 4.13 4.12 / 4.17
Energy class (cooling / heating) - A / A A / A
Noise level cooling (sound pressure) (night mode) dB(A) 49 (45) 49 (45)
Noise level heating (sound pressure) dB(A) 51 51
Air ow (cooling / heating) m
3
/min 90 / 90 90 / 90
Dimensions (H x W x D) mm 1380 / 950 / 370 1380 / 950 / 370
Net weight kg 100 102
Gross weight kg 113 115
Power supply - 1~ 230V 50Hz 3N~ 400V 50Hz
Recommended fuse size A 32 20
Starting current A Less than maximum current Less than maximum current
Maximum current A 26 13
Running current cooling A 12.2 4.1
Running current heating A 13.4 4.6
Power cable size (according to EN 60335-1)
quantity x
mm²
3 x 6.0 5 x 4.0
Transmitting cable size between indoor unit and
outdoor unit
quantity x
mm²
2 x 0.75 2 x 0.75
Piping diameter (liquid / gas) mm (inch) Ø9.53 (3/8) / Ø15.88 (5/8) Ø9.53 (3/8) / Ø15.88 (5/8)
Refrigerant charge before shipment kg 3.6 3.6
Maximum piping length (additional refrigerant
charge needed)
m (g/m) 75 (need to be calculated) 75 (need to be calculated)
Height difference (O.U. higher / O.U. lower) m 30 / 30 30 / 30
Working range (cooling // heating) °C -5 / +46 (DB) // -20 / +15(WB) -5 / +46 (DB) // -20 / +15(WB)
Refrigerant - R410A R410A
Compressor type - Scroll DC Inverter driven Scroll DC Inverter driven
N O T E
• (*1): Please, refer to the chapter Piping work and refrigerant charge for the specic considerations.
• (*2) Calculated with outdoor input only.
