2 Features and benets
23
TCGB0068 rev.1 - 08/2012
2
2.4.4 Advanced technology
The functionality benets explained before (Highly efciency system, wide capacity range and expanded working range)
are direct consequence of the advanced technology applied on all the system components.
Then, the main features on different components of the system will be detailed:
O
P
Refrigerant ow for cooling Refrigerant ow for heating
A: Super high-stream fan. N: Highly efcient scroll compressor.
B: Side-ow technology. O: Two stage oil separator technology.
C: Silent fan unit. P: Reduced power consumption.
D: DC fan motor with outstanding efciency. Q: High pressure shell.
E: Outdoor unit heat exchanger. R: Lubrication.
F: Outdoor unit expansion valve. S: Protection against liquid return.
G: Sub-cooling circuit. T: Efcient design of stator coils.
H: Reversing valve. U: DC compressor with neodymium magnet.
I: Improved performance by sub-cooling circuit. V: Low noise.
J: Gas by-pass. W: Stop valve of the liquid pipe.
K: Compressor. X: Indoor unit expansion valve.
L: Accumulator. Y: Indoor unit heat exchanger.
M: Stop valve of the gas pipe. Z: Oil separator
AA: Check valve
