4 Capacities and
selection data
53
TCGB0068 rev.1 - 08/2012
4
4.2.3  Cooling capacity tables according to total power of combined indoor units
N O T E
To: Outdoor air inlet temperature DB (°C)
Ti: Indoor air inlet temperature WB (ºC) / (DB (ºC))
CAP: Capacity at compressor maximum frequency (kW)
IPT: Input power (kW)
RAS-(4-6)FSVN2E
RAS-4FSVN2E
To
Total power of combined indoor units (50%) Total power of combined indoor units (60%)
Ti Ti
15/(21) 17/(24) 19/(27) 21/(29) 23/(31) 15/(21) 17/(24) 19/(27) 21/(29) 23/(31)
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
10
5.15 0.99 5.54 1.04 5.94 1.10 6.33 1.12 6.72 1.14 6.18 1.19 6.65 1.24 7.12 1.31 7.59 1.34 8.06 1.36
12
5.15 0.99 5.54 1.04 5.94 1.10 6.33 1.13 6.72 1.14 6.18 1.19 6.65 1.24 7.12 1.31 7.59 1.35 8.06 1.36
14
5.15 1.00 5.54 1.04 5.94 1.10 6.33 1.13 6.72 1.14 6.18 1.19 6.65 1.24 7.12 1.32 7.59 1.35 8.06 1.37
16
5.15 1.00 5.54 1.05 5.94 2.39 6.33 1.13 6.72 1.15 6.18 1.20 6.65 1.25 7.12 2.39 7.59 1.36 8.06 1.37
18
5.15 1.01 5.54 1.05 5.94 1.12 6.33 1.14 6.72 1.16 6.18 1.21 6.65 1.26 7.12 1.33 7.59 1.37 8.06 1.39
20
5.15 1.02 5.54 1.07 5.94 1.13 6.33 1.15 6.72 1.17 6.18 1.22 6.65 1.27 7.12 1.35 7.59 1.38 8.06 1.40
22
5.15 1.03 5.54 1.08 5.94 1.14 6.33 1.17 6.72 1.18 6.18 1.23 6.65 1.29 7.12 1.36 7.59 1.40 8.06 1.41
24
5.15 1.04 5.54 1.09 5.94 1.15 6.33 1.18 6.72 1.20 6.18 1.25 6.65 1.31 7.12 1.38 7.59 1.41 8.06 1.43
25
5.15 1.05 5.54 1.10 5.94 1.16 6.33 1.19 6.72 1.21 6.18 1.26 6.65 1.32 7.12 1.39 7.59 1.43 8.06 1.44
26
5.12 1.06 5.51 1.11 5.90 1.17 6.29 1.20 6.70 1.21 6.14 1.26 6.61 1.32 7.08 1.40 7.55 1.43 8.04 1.45
28
5.05 1.07 5.44 1.12 5.84 1.18 6.23 1.21 6.65 1.22 6.06 1.28 6.53 1.33 7.00 1.41 7.47 1.44 7.98 1.46
30
4.98 1.08 5.38 1.13 5.77 1.19 6.16 1.22 6.61 1.23 5.98 1.29 6.45 1.35 6.92 1.42 7.39 1.46 7.93 1.47
32
4.92 1.11 5.31 1.16 5.70 1.22 6.09 1.25 6.52 1.26 5.90 1.32 6.37 1.38 6.84 1.46 7.31 1.49 7.82 1.51
34
4.85 1.14 5.24 1.19 5.63 1.25 6.03 1.28 6.43 1.29 5.82 1.36 6.29 1.42 6.76 1.49 7.23 1.53 7.71 1.55
35
4.82 1.15 5.21 1.20 5.60 1.27 5.99 1.29 6.38 1.31 5.78 1.38 6.25 1.44 6.72 1.51 7.19 1.55 7.66 1.57
36
4.77 1.19
5.16
1.23 5.56 1.30 5.95 1.33 6.33 1.34 5.73 1.42 6.20 1.48 6.67 1.55 7.14 1.59 7.59 1.61
38
4.68 1.25 5.07 1.30 5.47 1.36 5.86 1.39 6.22 1.41 5.62 1.50 6.09 1.55 6.56 1.63 7.03 1.67 7.46 1.69
40
4.59 1.32 4.98 1.37 5.38 1.43 5.77 1.46 6.10 1.48 5.51 1.57 5.98 1.63 6.45 1.71 6.92 1.75 7.32 1.77
To
Total power of combined indoor units (70%) Total power of combined indoor units (80%)
Ti Ti
15/(21) 17/(24) 19/(27) 21/(29) 23/(31) 15/(21) 17/(24) 19/(27) 21/(29) 23/(31)
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
10
7.21 1.40 7.76 1.47 8.31 1.55 8.86 1.59 9.41 1.61 8.24 1.64 8.87 1.71 9.50 1.81 10.12 1.86 10.75 1.88
12
7.21 1.40 7.76 1.47 8.31 1.55 8.86 1.59 9.41 1.61 8.24 1.64 8.87 1.71 9.50 1.82 10.12 1.86 10.75 1.88
14
7.21 1.41 7.76 1.47 8.31 1.56 8.86 1.59 9.41 1.61 8.24 1.65 8.87 1.72 9.50 1.82 10.12 1.86 10.75 1.89
16
7.21 1.42 7.76 1.48 8.31 2.39 8.86 1.60 9.41 1.62 8.24 1.66 8.87 1.73 9.50 2.39 10.12 1.87 10.75 1.90
18
7.21 1.42 7.76 1.49 8.31 1.58 8.86 1.62 9.41 1.64 8.24 1.67 8.87 1.74 9.50 1.84 10.12 1.89 10.75 1.91
20
7.21 1.44 7.76 1.51 8.31 1.59 8.86 1.63 9.41 1.65 8.24 1.68 8.87 1.76 9.50 1.86 10.12 1.91 10.75 1.93
22
7.21 1.46 7.76 1.52 8.31 1.61 8.86 1.65 9.41 1.67 8.24 1.70 8.87 1.78 9.50 1.88 10.12 1.93 10.75 1.95
24
7.21 1.48 7.76 1.54 8.31 1.63 8.86 1.67 9.41 1.69 8.24 1.73 8.87 1.80 9.50 1.91 10.12 1.95 10.75 1.98
25
7.21 1.49 7.76 1.56 8.31 1.64 8.86 1.68 9.41 1.71 8.24 1.74 8.87 1.82 9.50 1.92 10.12 1.97 10.75 2.00
26
7.17 1.49 7.71 1.56 8.26 1.65 8.81 1.69 9.38 1.71 8.19 1.75 8.82 1.83 9.44 1.93 10.07 1.98 10.72 2.00
28
7.07 1.51 7.62 1.58 8.17 1.67 8.72 1.71 9.31 1.73 8.08 1.77 8.71 1.84 9.34 1.95 9.96 1.99 10.64 2.02
30
6.98 1.52 7.53 1.59 8.08 1.68 8.62 1.72 9.25 1.74 7.97 1.78 8.60 1.86 9.23 1.96 9.86 2.01 10.57 2.04
32
6.88 1.57 7.43 1.63 7.98 1.72 8.53 1.76 9.13 1.79 7.87 1.83 8.49 1.91 9.12 2.01 9.75 2.06 10.43 2.09
34
6.79 1.61 7.34 1.68 7.89 1.77 8.44 1.81 9.00 1.83 7.76 1.88 8.39 1.96 9.01 2.06 9.64 2.11 10.29 2.14
35
6.74 1.63 7.29 1.70 7.84 1.79 8.39 1.83 8.94 1.85 7.71 1.91 8.33 1.99 8.96 2.09 9.59 2.14 10.21 2.16
36
6.68 1.68 7.23 1.74 7.78 1.83 8.33 1.88 8.86 1.90 7.63 1.96 8.26 2.04 8.89 2.14 9.52 2.19 10.12 2.22
38
6.55 1.77 7.10 1.84 7.65 1.93 8.20 1.97 8.70 2.00 7.49 2.07 8.12 2.15 8.74 2.25 9.37 2.30 9.95 2.33
40
6.43 1.86 6.98 1.93 7.53 2.02 8.08 2.06 8.55 2.09 7.35 2.17 7.97 2.26 8.60 2.36 9.23 2.41 9.77 2.45
