![Hitachi RAS-5FSNY2E [90/148] Total power of combined indoor units 110 total power of combined indoor units 120 ti ti 16 18 20 22 24 16 18 20 22 24 cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt 20](/img/pdf.png)
Hitachi RAS-5FSNY2E [90/148] Total power of combined indoor units 110 total power of combined indoor units 120 ti ti 16 18 20 22 24 16 18 20 22 24 cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt 20
![Hitachi RAS-5FSVN2E [90/148] Total power of combined indoor units 110 total power of combined indoor units 120 ti ti 16 18 20 22 24 16 18 20 22 24 cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt cap ipt 20](/views2/1321845/page90/bg5a.png)
4 Capacities and
selection data
82
TCGB0068 rev.1 - 08/2012
To
Total power of combined indoor units (110%) Total power of combined indoor units (120%)
Ti Ti
16 18 20 22 24 16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
9.44 3.24 9.12 3.38 9.12 3.55 8.96 3.71 8.80 3.88 9.44 3.14 9.12 3.28 9.12 3.44 8.96 3.59 8.80 3.76
-17
9.73 3.26 9.50 3.41 9.41 3.57 9.25 3.73 9.18 3.91 9.73 3.16 9.50 3.30 9.41 3.46 9.25 3.62 9.18 3.79
-15
9.92 3.29 9.76 3.44 9.60 3.60 9.44 3.76 9.44 3.94 9.92 3.19 9.76 3.33 9.60 3.49 9.44 3.64 9.44 3.82
-13
10.30 3.32 10.14 3.46 9.98 3.63 9.82 3.79 9.82 3.97 10.30 3.22 10.14 3.36 9.98 3.52 9.82 3.67 9.82 3.84
-11
10.69 3.35 10.53 3.49 10.37 3.66 10.21 3.82 10.21 3.99 10.69 3.24 10.53 3.38 10.37 3.54 10.21 3.70 10.21 3.87
-10
10.88 3.38 10.72 3.52 10.56 3.69 10.40 3.85 10.40 4.02 10.88 3.27 10.72 3.41 10.56 3.57 10.40 3.73 10.40 3.90
-9
11.14 3.40 10.98 3.55 10.85 3.71 10.72 3.87 10.72 4.05 11.14 3.30 10.98 3.44 10.85 3.60 10.72 3.75 10.72 3.92
-7
11.65 3.43 11.49 3.58 11.42 3.74 11.36 3.90 11.36 4.08 11.65 3.33 11.49 3.46 11.42 3.63 11.36 3.78 11.36 3.95
-6
11.90 3.46 11.74 3.60 11.71 3.77 11.68 3.93 11.68 4.11 11.90 3.35 11.74 3.49 11.71 3.65 11.68 3.81 11.68 3.98
-5
12.16 3.49 12.00 3.63 12.00 3.80 12.00 3.96 12.00 4.13 12.16 3.38 12.00 3.52 12.00 3.68 12.00 3.83 12.00 4.00
-3
12.86 3.52 12.77 3.66 12.70 3.83 12.70 3.99 12.64 4.16 12.86 3.41 12.77 3.55 12.70 3.71 12.70 3.86 12.64 4.03
-1
13.57 3.54 13.54 3.69 13.41 3.85 13.41 4.01 13.28 4.19 13.57 3.43 13.54 3.57 13.41 3.73 13.41 3.89 13.28 4.06
0
13.92 3.57 13.92 3.72 13.76 3.88 13.76 4.04 13.60 4.22 13.92 3.46 13.92 3.60 13.76 3.76 13.76 3.92 13.60 4.09
1
14.30 3.60 14.30 3.74 14.14 3.91 14.11 4.07 13.95 4.25 14.30 3.49 14.30 3.63 14.14 3.79 14.11 3.94 13.95 4.11
3
15.07 3.63 15.07 3.77 14.91 3.94 14.82 4.10 14.66 4.27 15.07 3.51 15.07 3.65 14.91 3.81 14.82 3.97 14.66 4.14
5
15.84 3.66 15.84 3.80 15.68 3.97 15.52 4.13 15.36 4.30 15.84 3.54 15.84 3.68 15.68 3.84 15.52 4.00 15.36 4.17
6
16.32 3.68 16.16 3.83 16.00 3.99 15.84 4.15 15.68 4.33 16.32 3.57 16.16 3.71 16.00 3.87 15.84 4.02 15.68 4.19
7
16.68 3.71 16.48 3.86 16.36 4.02 16.20 4.18 16.00 4.36 16.68 3.60 16.48 3.74 16.36 3.90 16.20 4.05 16.00 4.22
9
17.40 3.74 17.12 3.88 17.08 4.05 16.92 4.21 16.64 4.39 17.40 3.62 17.12 3.76 17.08 3.92 16.92 4.08 16.64 4.25
10
17.76 3.77 17.44 3.91 17.44 4.08 17.28 4.24 16.96 4.41 17.76 3.65 17.44 3.79 17.44 3.95 17.28 4.11 16.96 4.28
11
17.89 3.80 17.57 3.94 17.54 4.11 17.38 4.27 17.06 4.44 17.89 3.68 17.57 3.82 17.54 3.98 17.38 4.13 17.06 4.30
14
18.27 3.82 17.95 3.97 17.82 4.13 17.66 4.29 17.34 4.47 18.27 3.70 17.95 3.84 17.82 4.00 17.66 4.16 17.34 4.33
15
18.40 3.85 18.08 4.00 17.92 4.16 17.76 4.32 17.44 4.50 18.40 3.73 18.08 3.87 17.92 4.03 17.76 4.19 17.44 4.36
To
Total power of combined indoor units (130%)
Ti
16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
9.44 3.00 9.12 3.13 9.12 3.29 8.96 3.44 8.80 3.60
-17
9.73 3.03 9.50 3.16 9.41 3.31 9.25 3.46 9.18 3.63
-15
9.92 3.05 9.76 3.19 9.60 3.34 9.44 3.49 9.44 3.65
-13
10.30 3.08 10.14 3.21 9.98 3.37 9.82 3.51 9.82 3.68
-11
10.69 3.10 10.53 3.24 10.37 3.39 10.21 3.54 10.21 3.70
-10
10.88 3.13 10.72 3.26 10.56 3.42 10.40 3.57 10.40 3.73
-9
11.14 3.16 10.98 3.29 10.85 3.44 10.72 3.59 10.72 3.75
-7
11.65 3.18 11.49 3.32 11.42 3.47 11.36 3.62 11.36 3.78
-6
11.90 3.21 11.74 3.34 11.71 3.50 11.68 3.64 11.68 3.81
-5
12.16 3.23 12.00 3.37 12.00 3.52 12.00 3.67 12.00 3.83
-3
12.86 3.26 12.77 3.39 12.70 3.55 12.70 3.70 12.64 3.86
-1
13.57 3.29 13.54 3.42 13.41 3.57 13.41 3.72 13.28 3.88
0
13.92 3.31 13.92 3.45 13.76 3.60 13.76 3.75 13.60 3.91
1
14.30 3.34 14.30 3.47 14.14 3.62 14.11 3.77 13.95 3.94
3
15.07 3.36 15.07 3.50 14.91 3.65 14.82 3.80 14.66 3.96
5
15.84 3.39 15.84 3.52 15.68 3.68 15.52 3.82 15.36 3.99
6
16.32 3.42 16.16 3.55 16.00 3.70 15.84 3.85 15.68 4.01
7
16.68 3.44 16.48 3.58 16.36 3.73 16.20 3.88 16.00 4.04
9
17.40 3.47 17.12 3.60 17.08 3.75 16.92 3.90 16.64 4.07
10
17.76 3.49 17.44 3.63 17.44 3.78 17.28 3.93 16.96 4.09
11
17.89 3.52 17.57 3.65 17.54 3.81 17.38 3.95 17.06 4.12
14
18.27 3.55 17.95 3.68 17.82 3.83 17.66 3.98 17.34 4.14
15
18.40 3.57 18.08 3.70 17.92 3.86 17.76 4.01 17.44 4.17
