3 General data
38
TCGB0068 rev.1 - 08/2012
3.2 Component data
3.2.1 RAS-(4-6)FSVN2E
Model RAS-4FSVN2E RAS-5FSVN2E RAS-6FSVN2E
Heat exchanger
Type Multi-pass cross-nned tube
Pipe material Copper
Outer diameter mm 7 7 7
Rows of tubes 2 2 2
No. of tubes in the Heat exchanger 132 132 132
Fin material Aluminium
Fin pitch 1.9 1.9 1.9
Maximum operating pressure MPa 4.15 4.15 4.15
Total front area m
2
1.35 1.35 1.35
No. of Heat exchanger per unit 1 1 1
Fan
Fan type Multi-blade turbo fan
Fans per unit 2 2 2
Outer diameter mm 544 544 544
Revolutions rpm 516+422 516+422 573+469
Nominal air ow m
3
/min 90 90 100
Motor
Shell Drip-proof enclosure
Starting Direct current control
Power W 74+74 74+74 74+74
Quantity 2 2 2
Insulation class E E E
Compressor E400HHD-36A2
3.2.2 RAS-(4-6)FSNY2E
Model RAS-4FSNY2E RAS-5FSNY2E RAS-6FSNY2E
Heat exchanger
Type Multi-pass cross-nned tube
Pipe material Copper
Outer diameter mm 7 7 7
Rows of tubes 2 2 2
No. of tubes in the Heat exchanger 132 132 132
Fin material Aluminium
Fin pitch 1.9 1.9 1.9
Maximum operating pressure MPa 4.15 4.15 4.15
Total front area m
2
1.35 1.35 1.35
No. of Heat exchanger per unit 1 1 1
Fan
Fan type Multi-blade turbo fan
Fans per unit 2 2 2
Outer diameter mm 544 544 544
Revolutions rpm 516+422 516+422 573+469
Nominal air ow m
3
/min 90 90 100
Motor
Shell Drip-proof enclosure
Starting Direct current control
Power W 74+74 74+74 74+74
Quantity 2 2 2
Insulation class E E E
Compressor E400HHD-36D2
