FG080 –EPSILON 07-12 RAC
43
1. POWER SUPPLY B801-93-019
2. POWER SUPPLY B801-93-005
3. TRAY SPRING A900-19-021
4. LMC20 B801-80-033
5. TRAY MOTOR B781-74-007
6. SAFETY SWITCH B801-07-005
7. TIMING PULLEY 080-02-00026
8. TIMING PULLEY 080-02-00020
9. TIMING BELT A900-21-107
10. TIMING PULLEY 080-02-00021
11. DEPOSIT MOTOR B781-74-008
12. GEARBOX A900-11-095
13. ADJUSTABLE FOOT A900-27-227
14. JOG MOTOR B781-74-006
15. HMI B801-93-018
16. CIRCUIT BREAKER B872-22-003
17. E-STOP RELAY B801-11-019
18. STOP BUTTON B801-12-003
19. CONTACT BLOCK B801-14-008 (N/C), B801-14-004 (N/O)
20. JOG SWITCH B842-07-029
21. TRAY SWITCH B842-07-030
ITEM
DESCRIPTION PART NUMBER
