22. TEMPLATE SAFETY SWITCH/MAGNET B801-07-006
23. HINGE FOR TEMPLATE SAFETY MAGNET A900-27-217
24. RETURN SPRING A900-19-094
25. BALLSCREW + NUT 080-02-00025
26. BEARING FOR BALLSCREW A900-06-009
27. VERTICAL SLIDES A900-31-054
28. V-ROLLER – CONCENTRIC A900-06-297
29. V-ROLLER – ECCENTRIC A900-06-298
30. TRACK ROLLER A900-06-136
31. TRAY GUIDE 080-08-00015
32. HOPPER LOCKING THUMSCREW A900-27-213
33. CIRCLIP – HOPPER DRIVESHAFT A900-01-193
34. WINGNUT FOR TRAY GUIDE A900-04-043
35. CABLE GUIDE STRAP 080-25-00006
36. MAINS CABLE GLANDS B900-17-002
37. BUMP STOPS A900-18-006
38. CIRCLIPS – BALLSCREW A900-01-112
39. PLATFORM FABRICATION 080-08-00001
(400 HOPPER VERSION) 080-08-00011
40. RACK 080-02-00032
41. PINION 080-02-00032
42. TRANS-TORQUE BUSH A900-10-011
