Wilo Plavis 013-C [23/60] Transport and interim storage

23WILO SE 09/2016

1. General

See start of document.

2. Safety

See start of document.

3. Transport and interim storage

When you receive the equipment, check that it

has not been damaged during transport. If you

notice any defects, take all necessary measures

with the carrier in the time provided.

WARNING! The environment may cause damage.

If the equipment delivered must be installed

subsequently, store it in a dry place and protect it

from shock and any other effects (humidity, frost,

etc.).

Transport and storage temperatures: -30 °C to

+60 °C.

Handle the product with care so as not to dam-

age it prior to installation.

4. Intended use

The Wilo-Plavis ...-C product is designed for pump-

ing condensates emitted by the following systems:

• Boiler

• Air-conditioning system

• Cooling and refrigeration system

• Airdehumidication

The product is suitable for pumping collected

condensates that cannot be sent towards the

drains or drained from the building by the natural

slope.

DANGER! Risk of explosion!

Donotusethispumptoconveyammableor

explosive liquids.

WARNING!

The condensates from boilers are aggressive due

to their acidity. Always wear gloves and protec-

tive glasses for maintenance work.

The condensates from boilers must be processed

(potentially neutralised) in compliance with the

local regulations before being sent to the drains.

5. Product information

5.2 Scope of delivery

• Wilo-Plavis ...-C

• + 2 fastening screws Ø 4

• + 5 m drainage pipe Ø 8 x 11 (based on the model)

• +Installationandoperatinginstructions(g.2)

6. Description and function

6.1 Description (g.3,4)

1 Pump set

2 Tankoverowsafetylevel(basedonthemodel)

3 Tank cover

4 Hatch (based on the model)

5 Plug adapter (based on the model)

6 Power supply

7 Alarmcable(basedonthemodel)

8 Non-return valve

9 Tank

10 Low-level probes

11 High-level probes

12 Alarm probe (based on the model)

13 Alarm indicator (based on the model)

A Suction

B Drainage

6.2 Function

• The condensates are collected in the tank

• The level of liquid is automatically controlled by

the electronic card

• The pump starts when the liquid level reaches

the high-level probe, and stops when the liquid

level has descended to the low-level probe

• The condensates are drained away through the

drainage piping

• The product is equipped with an alarm probe in

case of defect (based on the model). This alarm

probe activates the alarm relay that may be con-

nected via the alarm cable

7. Installation and electrical connection

WARNING! Physical injuries

The applicable regulations for the prevention of

accidents must be complied with.

WARNING! Risk of electric shock

Any danger posed by electricity must be eliminated.

5.1 Technical data

Designation Wilo-Plavis 011-C Wilo-Plavis 013-C Wilo-Plavis 015-C

Supply voltage 1 ~ 100-240 Vac

Frequency 50/60 Hz

Supply cable 1.5 m

Alarm cable - 1.5 m

Power consumption < 20 W

Rated current 0.2 A

Protection class IP X4

Ambient temperature from + 5 °C to + 40 °C

Alarm relay contact - 42 V rms 1A

Delivery head Max 4 m

Admissibleuid pH > 2.5

Admissibleuidtemperature from + 5 °C to + 60 °C

Sound-pressure level < 40 dBA at 1 m

Dimensions (L x W) 152 x 116 mm 210 x 123 mm 275x129mm

Tank volume 0.7L 1.1 L 1.6 L

Net weight (± 10 %) 700gr 750gr 1,000 gr
