Data Copy from USB Memory to TV set
1. Turn on the TV set.
2. Insert USB Memory with Data to USB Terminal.
On-screen Display will be appeared according to the Data folder automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement: 2771
(b) For Hotel: 4851
Data will be copied from USB Memory to TV set.
4. After the completion of copying to USB Memory, remove USB Memory from TV set.
(a) For Board replacement: Data will be deleted after copying (Limited one copy).
(b) For Hotel: Data will not be deleted and can be used for other TVs.
5. Turn off the TV set.
Note:
1. Depending on the failure of boards, function of Data for board replacement does not work.
2. This function can be effective among the same model numbers.
Input Password
Performing
Input Password
2771 or 4851
Performin
g
Com
p
letion
Performing
Data Copy(Board replacement )
Input password
-----
Data Copy(Board replacement )
Copy Media to TV
Please wait for a while
Please do not remove the Media
WRITING
Data Copy(Board replacement )
Data copy has been successful
Please turn off the TV for system
initializing
FINISH
19
