Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R8204 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8206 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8207 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8217 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R8218 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R8219 D1BA2400A023 M 240 OHM, F, 1/16W 1 PAVCCZ
R8220 D1BA2400A023 M 240 OHM, F, 1/16W 1 PAVCCZ
R8230 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8231 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8232 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8233 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8234 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8235 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8236 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8237 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8238 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8239 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8242 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R8244 D1BA2400A023 M 240 OHM, F, 1/16W 1 PAVCCZ
R8250 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8251 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R8300 D0GA221JA023 M 220 OHM, J, 1/16W 1 PAVCCZ
R8400 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8401 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8402 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8403 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8404 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8405 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R8409 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8411 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8413 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8414 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8415 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8416 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R8417 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R8418 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8422 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8423 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8424 D1H84704A042 M 47 OHM, J, 1/16W 1 PAVCCZ
R8425 D1H84704A042 M 47 OHM, J, 1/16W 1 PAVCCZ
R8426 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8427 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8428 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R8441 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8443 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8444 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R8445 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R8446 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8447 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8448 D1H84704A042 M 47 OHM, J, 1/16W 1 PAVCCZ
R8449 D1H84704A042 M 47 OHM, J, 1/16W 1 PAVCCZ
R8450 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8451 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8452 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8453 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R8601 D1BA75R0A023 M 75 OHM, F, 1/16W 1 PAVCCZ
R8602 D1BA75R0A023 M 75 OHM, F, 1/16W 1 PAVCCZ
R8603 D1BA75R0A023 M 75 OHM, F, 1/16W 1 PAVCCZ
R8604 D1BA75R0A023 M 75 OHM, F, 1/16W 1 PAVCCZ
R8605 D1BA2402A023 M 24K OHM, F, 1/16W 1 PAVCCZ
R8608 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8609 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
45
