Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
PCB A-L42ET60B CIRCUIT BOARD A 1 (TX-L42ET60B) PAVCCZ
PCB A-L42ET60Y CIRCUIT BOARD A 1 (TX-L42ET60Y) PAVCCZ
PCB A-LR42ET60 CIRCUIT BOARD A 1 (TX-LR42ET60) PAVCCZ
PCB TXN/K1YDUE CIRCUIT BOARD K 1 PAVCCZ
PCB TXN/P1YDUE CIRCUIT BOARD P 1 PAVCCZ
PCB TXNGK1YDUE CIRCUIT BOARD GK 1 PAVCCZ
A02 K1KY14BA0484 14P CONNECTOR 1 PAVCCZ
A10 K1KY07BA0483 7P CONNECTOR 1 PAVCCZ
A12 K1KY06BA0387 6P CONNECTOR 1 PAVCCZ
A15 K1MY41BA0526 41P CONNECTOR 1 PAVCCZ
A16 K1MY51BA0526 51P CONNECTOR 1 PAVCCZ
A20 K1FY105E0017 USB TERMINAL 1 PAVCCZ
C2000 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C2009 F1G1H1020008 C 1NF, , 50V 1 PAVCCZ
C2012 F1G1E103A059 C 10NF, , 25V 1 PAVCCZ
C2014 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C2023 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C2801 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C2804 F1H1C104A178 C 0.1UF, -, 16V 1 PAVCCZ
C2807 F1J1A106A043 C 10UF, , 10V 1 PAVCCZ
C3000 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C3001 F1G1H221A830 C 220PF, -, 50V 1 PAVCCZ
C3002 F1G1H470A834 C 47PF, , 50V 1 PAVCCZ
C3003 F1G1H470A834 C 47PF, , 50V 1 PAVCCZ
C3004 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3005 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3006 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3007 F1G1H470A834 C 47PF, , 50V 1 PAVCCZ
C3008 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3009 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3010 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3011 F1G1H100A833 C 10PF, , 50V 1 PAVCCZ
C3012 F1G1H152A830 C 1500PF, , 50V 1 PAVCCZ
C3013 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3014 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3015 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3016 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3025 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3026 F1G1A473A069 C 47NF, , 10V 1 PAVCCZ
C3027 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3028 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3029 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C3032 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3033 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3036 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3037 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C3042 F1G1A473A069 C 47NF, , 10V 1 PAVCCZ
C3043 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C3044 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C3045 F1G1H101A834 C 100PF, , 50V 1 PAVCCZ
C3046 F1G1H101A834 C 100PF, , 50V 1 PAVCCZ
C3047 F1G1H101A834 C 100PF, , 50V 1 PAVCCZ
C3048 F1G1H101A834 C 100PF, , 50V 1 PAVCCZ
C3105 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3106 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3135 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3136 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3139 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
C3140 F1G1H471A834 C 470PF, , 50V 1 PAVCCZ
31
