Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R4707 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4708 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4709 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4710 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4711 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4712 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4713 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4714 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4715 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4717 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4718 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4720 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4721 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4722 D1BA1800A023 M 180 OHM, F, 1/16W 1 PAVCCZ
R4723 D1BA82R0A023 M 82 OHM, F, 1/16W 1 PAVCCZ
R4725 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4726 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4751 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4752 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4753 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4754 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4755 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4757 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4758 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4900 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4901 D0GFR00J0005 M 0 OHM, J, 1/4W 1 PAVCCZ
R4902 D1H86804A042 M 68 OHM, J, 1/16W 1 PAVCCZ
R4903 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4904 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4910 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4930 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4960 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4961 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4962 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R4963 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R5002 D0GA683JA023 M 68K OHM, J, 1/16W 1 PAVCCZ
R5003 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R5006 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R5007 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R5009 D1BA5602A023 M 56K OHM, F, 1/16W 1 PAVCCZ
R5012 D1BA2202A023 M 22K OHM, F, 1/16W 1 PAVCCZ
R5101 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R5140 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R5141 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R5143 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R5144 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R5171 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R5172 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R5175 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R5176 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R5177 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R5178 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R5179 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R5203 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R5204 D0GA822JA023 M 8K2 OHM, J, 1/16W 1 PAVCCZ
R5207 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R5215 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R5312 D0GA220JA023 M 22 OHM, J, 1/16W 1 PAVCCZ
R5315 D1BA1402A023 M 14K OHM, F, 1/16W 1 PAVCCZ
R5316 D1BA1001A023 M 1K OHM, F, 1/16W 1 PAVCCZ
R5317 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R5318 D1BA3902A023 M 39K OHM, F, 1/16W 1 PAVCCZ
