Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
TUC5ZJ50291 HEATSINK FRONT 1 PAVCCZ
TUC5ZJ50491 HEATSINK REAR 1 PAVCCZ
XTS4+10GFN SCREW 5 PAVCCZ
XYN4+F10FNK SCREW M4X10 4 PAVCCZ
XYN5+F18FN SCREW M5X18 8 PAVCCZ
BOTCUS TPD0E22641 CUSHION BOTTOM 1 PAVCCZ
CA01 TMME442 SPACER HEATSINK HOLD 1 PAVCCZ
CA02 TMME442 SPACER HEATSINK HOLD 1 PAVCCZ
CA03 TMME442 SPACER HEATSINK HOLD 1 PAVCCZ
CA04 TMME442 SPACER HEATSINK HOLD 1 PAVCCZ
CARTON TPC0EA09902 CARTON 1 PAVCCZ
CENCUS TPD0E50241 CUSHION FRONT 1 PAVCCZ
CK301 TMME386 CLAMPER 1 PAVCCZ
FA03 TMK0EA267 FELT(5X72XT0.35) 1 PAVCCZ
FA07 TMKK488 A-THERMAL RUBBER DDR (10X10X4) 1 PAVCCZ
FA09 TMKK534 RUBBER MTK FRONT 1 PAVCCZ
FA10 TMKK535 RUBBER MTK REAR 1 PAVCCZ
FK201 TMK0EA389 FELT(15X120XT0.5) 1 PAVCCZ
FK202 TMK0EA389 FELT(15X120XT0.5) 1 PAVCCZ
FK203 TMK0EA389 FELT(15X120XT0.5) 1 PAVCCZ
FK204 TMK0EA216 FELT(5X95XT0.5) 1 PAVCCZ
FK205 TMK0EA271 FELT(5X30XT0.5) 1 PAVCCZ
FK206 TMK0EG081 SPONGE(60X10XT2) 1 PAVCCZ
FK207 TMK0EG081 SPONGE(60X10XT2) 1 PAVCCZ
FK210 TMK0EG099 SPONGE 1 PAVCCZ
FK211 TMK0EG099 SPONGE 1 PAVCCZ
FK301 TEWF411 AL-PET TAPE(W10XL120) 1 PAVCCZ
FK302 TEWF411 AL-PET TAPE(W10XL120) 1 PAVCCZ
FK305 TMK0EA094 FELT(10X25XT0.3) 1 PAVCCZ
FK307 TMK0EA217 FELT(5X55XT0.5) 1 PAVCCZ
FK308 TMK0EA355 FELT(10X85XT0.5) 1 PAVCCZ
FK310 TMKK391 HEAT RUBBER(15X20X2.5) 1 PAVCCZ
FK311 TMKK391 HEAT RUBBER(15X20X2.5) 1 PAVCCZ
FK312 TMKK391 HEAT RUBBER(15X20X2.5) 1 PAVCCZ
FK313 TMK0EA179 FELT(5X8X0.5) 1 PAVCCZ
FK315 TMK0EG098 SPONGE 1 PAVCCZ
GA01 TEWB770 GASKET(W10XL15XT3.0) 1 PAVCCZ
SK201 THEC1509 SCREW 1 PAVCCZ
SK202 THEC1509 SCREW 1 PAVCCZ
SK203 THEC1509 SCREW 1 PAVCCZ
SK204 THEC1509 SCREW 1 PAVCCZ
SK205 THEC1509 SCREW 1 PAVCCZ
SK206 THEC1509 SCREW 1 PAVCCZ
SK207 THEC1509 SCREW 1 PAVCCZ
SK208 THEC1509 SCREW 1 PAVCCZ
SK209 THEC1509 SCREW 1 PAVCCZ
SK210 THEC1509 SCREW 1 PAVCCZ
SK211 THEC1509 SCREW 1 PAVCCZ
SK212 THEC1509 SCREW 1 PAVCCZ
SK213 THEC1509 SCREW 1 PAVCCZ
SK214 THEC1509 SCREW 1 PAVCCZ
SK215 THEC1509 SCREW 1 PAVCCZ
SK216 THEC1509 SCREW 1 PAVCCZ
SK217 THEC1509 SCREW 1 PAVCCZ
SK218 THEC1509 SCREW 1 PAVCCZ
SK219 THEC1509 SCREW 1 PAVCCZ
SK220 THEC1509 SCREW 1 PAVCCZ
SK221 THEC1509 SCREW 1 PAVCCZ
SK222 THEC1509 SCREW 1 PAVCCZ
SK223 THEC1509 SCREW 1 PAVCCZ
SK224 THEC1509 SCREW 1 PAVCCZ
SK225 THEC1509 SCREW 1 PAVCCZ
49
