Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R5400 D0GA220JA023 M 22 OHM, J, 1/16W 1 PAVCCZ
R5401 D1BA2202A023 M 22K OHM, F, 1/16W 1 PAVCCZ
R5402 D0GB911ZA037 M 910 OHM, J, 1/10W 1 PAVCCZ
R5403 D1BB2871A106 M 2K87 OHM, F, 1/10W 1 PAVCCZ
R5442 D1BB1241A196 M 1K24 OHM, D, 1/10W 1 PAVCCZ
R5443 D1BB6801A195 M 6K8 OHM, D, 1/10W 1 PAVCCZ
R5446 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
R5447 D1BA1502A023 M 15K OHM, F, 1/16W 1 PAVCCZ
R5713 D0GA220JA023 M 22 OHM, J, 1/16W 1 PAVCCZ
R5715 D1BA3242A023 M 32K4 OHM, F, 1/16W 1 PAVCCZ
R5716 D1BA1502A023 M 15K OHM, F, 1/16W 1 PAVCCZ
R5717 D0GA123JA023 M 12K OHM, J, 1/16W 1 PAVCCZ
R5736 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R6717 D0GBR00J0004 M 0 OHM, J, 1/10W 1 PAVCCZ
R6725 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6726 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6727 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6730 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R6743 D0GA681JA023 M 680 OHM, J, 1/16W 1 PAVCCZ
R6744 D0GA681JA023 M 680 OHM, J, 1/16W 1 PAVCCZ
R6804 D0GA681JA023 M 680 OHM, J, 1/16W 1 PAVCCZ
R6805 D0GA681JA023 M 680 OHM, J, 1/16W 1 PAVCCZ
R6810 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R6812 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6813 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6818 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6819 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6820 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6821 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6840 D0GA471JA023 M 470 OHM, J, 1/16W 1 PAVCCZ
R6846 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6847 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6848 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6849 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6850 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6861 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6862 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6863 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R6871 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R6872 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R6880 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6881 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R6882 D0GBR00J0004 M 0 OHM, J, 1/10W 1 PAVCCZ
R6884 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R7101 D0GF105JA048 M 1M OHM, J, 1/4W 1 PAVCCZ
R7102 D0GF105JA048 M 1M OHM, J, 1/4W 1 PAVCCZ
R7103 D0GF105JA048 M 1M OHM, J, 1/4W 1 PAVCCZ
R7201 ERX1SJR22V M R22 OHM, J, 1W 1 PAVCCZ
R7202 ERX1SJR22V M R22 OHM, J, 1W 1 PAVCCZ
R7203 D0GB513JA065 M 51K OHM, J, 1/10W 1 PAVCCZ
R7204 D0GF101JA047 M 100 OHM, J, - 1 PAVCCZ
R7205 D0GD470JA052 M 47 OHM, J, 1/8W 1 PAVCCZ
R7206 D0GD4R7JA059 M 4R7 OHM, J, 1/4W 1 PAVCCZ
R7207 D0GB473JA065 M 47K OHM, J, 1/10W 1 PAVCCZ
R7209 D0AF2R2JA112 C 2R2 OHM, J, 1/2W 1 PAVCCZ
R7211 D0GD104JA052 M 100K OHM, J, 1/8W 1 PAVCCZ
R7212 D0GD683JA052 M 68K OHM, J, 1/8W 1 PAVCCZ
R7219 D0GD513JA052 M 51K OHM, J, 1/8W 1 PAVCCZ
R7220 D0GD223JA052 M 22K OHM, J, 1/8W 1 PAVCCZ
R7224 D1BD8203A066 M 820K OHM, F, 1/8W 1 PAVCCZ
R7225 D1BF1504A073 M 1M5 OHM, F, 1/4W 1 PAVCCZ
R7226 D1BF1504A073 M 1M5 OHM, F, 1/4W 1 PAVCCZ
43
