Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R8610 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8611 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8612 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8613 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8614 D0GA272JA023 M 2K7 OHM, J, 1/16W 1 PAVCCZ
R8615 D0GA272JA023 M 2K7 OHM, J, 1/16W 1 PAVCCZ
R8618 D1BA3742A023 M 37K4 OHM, F, 1/16W 1 PAVCCZ
R8619 D1BA1822A023 M 18K2 OHM, F, 1/16W 1 PAVCCZ
R8623 D0GA272JA023 M 2K7 OHM, J, 1/16W 1 PAVCCZ
R8624 D1BB2000A106 M 200 OHM, F, 1/10W 1 PAVCCZ
R8632 D1BA3742A023 M 37K4 OHM, F, 1/16W 1 PAVCCZ
R8660 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8661 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8662 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8663 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8664 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8665 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R8666 D1HY1038A012 M 10K OHM, J, 1/16W 1 PAVCCZ
R8667 D1H85604A042 M 56 OHM, J, 1/16W 1 PAVCCZ
R8668 D1H85604A042 M 56 OHM, J, 1/16W 1 PAVCCZ
R8669 D0GA560JA023 M 56 OHM, J, 1/16W 1 PAVCCZ
R8671 D1BB1200A106 M 120 OHM, F, 1/10W 1 PAVCCZ
R8760 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R8761 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8762 D0GA153JA023 M 15K OHM, J, 1/16W 1 PAVCCZ
R8763 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8797 D1BA1200A023 M 120 OHM, F, 1/16W 1 PAVCCZ
R8798 D1BA56R0A023 M 56 OHM, F, 1/16W 1 PAVCCZ
R8801 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8802 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8805 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8806 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8807 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8812 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8814 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R8815 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8817 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8823 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8854 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R8901 D1H81034A042 M 10K OHM, J, 1/16W 1 PAVCCZ
R8902 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8905 D0GA222JA023 M 2K2 OHM, J, 1/16W 1 PAVCCZ
R8906 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R8910 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R8913 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R8914 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R8915 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
R8942 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8943 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R8944 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R9005 D0GA153JA023 M 15K OHM, J, 1/16W 1 PAVCCZ
R9006 D0GA472JA023 M 4K7 OHM, J, 1/16W 1 PAVCCZ
RM2800 B3RBB0000018 IR RECEIVER 1 PAVCCZ
SN2800 B3JB00000208 AI SENSOR IC 1 PAVCCZ
SW2851 EVQ11G05R LIGHT TOUCH SWITCH 1 PAVCCZ
SW2852 EVQ11G05R LIGHT TOUCH SWITCH 1 PAVCCZ
SW2853 EVQ11G05R LIGHT TOUCH SWITCH 1 PAVCCZ
SW2854 EVQ11G05R LIGHT TOUCH SWITCH 1 PAVCCZ
SW2855 EVQ11G05R LIGHT TOUCH SWITCH 1 PAVCCZ
46
