Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
IC5203 C0EBD0000300 IC VOLTAGE DETECTOR 1 PAVCCZ
IC5300 C0DBAYY01648 IC STEP-DOWN DC/DC CONVERTER 1 PAVCCZ
IC5702 C0DBAYY01656 IC DC/DC CONVERTER 1 PAVCCZ
IC6800 C1AB00004028 IC DVB-T2/T/C DEMODULATOR 1 PAVCCZ
IC7201 C0DBBYY00058 IC PFC 1 PAVCCZ
IC7301 C0DBAYY01329 IC CURRENT RESONANT CONTROLLER 1 PAVCCZ
IC7401 C0DBZYY00614 IC LOW VOLTAGE REGULATOR 1 PAVCCZ
IC7503 C0DBAYY01599 IC DC/DC CONVERTER 1 PAVCCZ
IC8000 C1AB00004072 IC PEAKS-PARAGON (MTK) 1 PAVCCZ
IC8100 C0DBAYY01644 IC STEP-DOWN DC/DC CONVERTER 1 PAVCCZ
IC8101 C0DBAYY01692 IC DC/DC CONVERTER 1 PAVCCZ
IC8200 C3ABUY000028 IC 2GBIT DDR3+SDRAM 1 PAVCCZ
IC8201 C3ABUY000028 IC 2GBIT DDR3+SDRAM 1 PAVCCZ
IC8202 C3ABTY000076 IC 1GBIT DDR3+SDRAM 1 PAVCCZ
IC8400 C0DBZYY00382 IC SWITCH 1 PAVCCZ
IC8602 C0DBZYY00541 IC SWITCH 1 PAVCCZ
IC8603 C0DBZYY00541 IC SWITCH 1 PAVCCZ
IC8605 C0DBZYY00541 IC SWITCH 1 PAVCCZ
IC8660 C0DBEYY00102 IC REGULATOR 1 PAVCCZ
IC8704 C0DBAYY01647 IC DC/DC CONVERTER 1 PAVCCZ
IC8705 C0DBAYY01299 IC STEP-DOWN DC/DC CONVERTER 1 PAVCCZ
IC8706 C0DBGYY01682 IC REVERSE CURRENT PROTECTION 1 PAVCCZ
IC8714 C0DBEYY00102 IC REGULATOR 1 PAVCCZ
IC8900 TVRL42ET60B FLASH MEMORY 1 (TX-L42ET60B) PAVCCZ
IC8900 TVRL42ET60Y FLASH MEMORY 1 (TX-L42ET60Y) PAVCCZ
IC8900 TVRLR42ET60 FLASH MEMORY 1 (TX-LR42ET60) PAVCCZ
JA1 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA10 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA11 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA12 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA13 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA2 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA4 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA5 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA8 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JA9 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
JK3002 K1FY120E0004 20P SCART TERMINAL 1 PAVCCZ
JK3101 K1U510E00001 YUV_V/AUDIO IN TERMINAL 1 PAVCCZ
JK3202 K2HC1YYB0079 HP TERMINAL 1 PAVCCZ
JK4701 K1FY119E0070 HDMI TERMINAL 1 PAVCCZ
JK4702 K1FY119E0070 HDMI TERMINAL 1 PAVCCZ
JK4703 K1FY119E0070 HDMI TERMINAL 1 PAVCCZ
JK7101 K2AAYB000010 AC INLET 1 PAVCCZ
JK8400 K1NA68E00115 CI CONNECTOR 1 PAVCCZ
JK8600 K1NA12E00016 SD SLOT 1 PAVCCZ
JK8601 K1FY104B0093 USB TERMINAL 1 PAVCCZ
JK8602 K1FY104B0093 USB TERMINAL 1 PAVCCZ
JK8650A K2LC1YYE0004 ETHERNET TERMINAL 1 PAVCCZ
JS0033 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
JS0061 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
JS7406 D0GDR00J0004 M 0 OHM, J, 1/8W 1 PAVCCZ
K10 K1KY07AA1311 7P CONNECTOR 1 PAVCCZ
L3000 G1C2R2MA0072 COIL 1 PAVCCZ
L3001 J0JYC0000156 FILTER 1 PAVCCZ
L3013 J0JYC0000156 FILTER 1 PAVCCZ
L3014 J0JYC0000156 FILTER 1 PAVCCZ
L4000 J0ZZB0000147 FILTER 1 PAVCCZ
38
