Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
Q4700 B1ABCF000231 TRANSISTOR 1 PAVCCZ
Q4701 B1ABCF000231 TRANSISTOR 1 PAVCCZ
Q4750 B1ABCF000231 TRANSISTOR 1 PAVCCZ
Q5140 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q5141 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q5142 B1ADCE000022 TRANSISTOR 1 PAVCCZ
Q5143 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q7201 B1CERR000085 TRANSISTOR 1 PAVCCZ
Q7202 B1ADCE000022 TRANSISTOR 1 PAVCCZ
Q7301 B1CFRR000016 TRANSISTOR 1 PAVCCZ
Q7302 B1CFRR000016 TRANSISTOR 1 PAVCCZ
Q7303 B1ADCE000022 TRANSISTOR 1 PAVCCZ
Q7401 B1ABCF000231 TRANSISTOR 1 PAVCCZ
Q7402 B1CHRE000015 TRANSISTOR 1 PAVCCZ
Q7403 B1CHRE000015 TRANSISTOR 1 PAVCCZ
Q7404 B1CHRE000015 TRANSISTOR 1 PAVCCZ
Q7407 B1CBGD000001 TRANSISTOR 1 PAVCCZ
Q7501 B1ABGE000015 TRANSISTOR 1 PAVCCZ
Q8750 B1ABBE000003 TRANSISTOR 1 PAVCCZ
Q8751 B1ABBE000003 TRANSISTOR 1 PAVCCZ
R0900 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R0901 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0902 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0903 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0904 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0905 D0GA330JA023 M 33 OHM, J, 1/16W 1 PAVCCZ
R0906 D0GA330JA023 M 33 OHM, J, 1/16W 1 PAVCCZ
R0908 D0GA272JA023 M 2K7 OHM, J, 1/16W 1 PAVCCZ
R0911 D0GA272JA023 M 2K7 OHM, J, 1/16W 1 PAVCCZ
R0926 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R0927 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R0928 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0929 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R0935 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R2003 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2004 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R2007 D0GA680JA023 M 68 OHM, J, 1/16W 1 PAVCCZ
R2008 D0GA153JA023 M 15K OHM, J, 1/16W 1 PAVCCZ
R2009 D1BA1002A023 M 10K OHM, F, 1/16W 1 PAVCCZ
R2010 D1BA7151A023 M 7K15 OHM, F, 1/16W 1 PAVCCZ
R2011 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R2012 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R2013 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2016 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2034 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2040 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R2051 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2056 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2058 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R2059 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R2060 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R2061 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R2062 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2067 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2802 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2807 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R2820 D0GA470JA023 M 47 OHM, J, 1/16W 1 PAVCCZ
R2821 D0GA223JA023 M 22K OHM, J, 1/16W 1 PAVCCZ
R2822 D0GA823JA023 M 82K OHM, J, 1/16W 1 PAVCCZ
R2823 D1BA1821A023 M 1K82 OHM, F, 1/16W 1 PAVCCZ
R2824 D1BA6800A023 M 680 OHM, F, 1/16W 1 PAVCCZ
40
