Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
L4001 J0ZZB0000147 FILTER 1 PAVCCZ
L4002 J0ZZB0000147 FILTER 1 PAVCCZ
L4003 J0ZZB0000147 FILTER 1 PAVCCZ
L4004 J0ZZB0000147 FILTER 1 PAVCCZ
L4005 J0ZZB0000147 FILTER 1 PAVCCZ
L4006 J0ZZB0000147 FILTER 1 PAVCCZ
L4007 J0ZZB0000147 FILTER 1 PAVCCZ
L4008 J0ZZB0000147 FILTER 1 PAVCCZ
L4009 J0ZZB0000147 FILTER 1 PAVCCZ
L4010 J0ZZB0000147 FILTER 1 PAVCCZ
L4011 J0ZZB0000147 FILTER 1 PAVCCZ
L4901 G1C100MA0533 COIL 1 PAVCCZ
L4902 G1C100MA0533 COIL 1 PAVCCZ
L4903 G1C100MA0533 COIL 1 PAVCCZ
L4904 G1C100MA0533 COIL 1 PAVCCZ
L4951 G1C220MA0533 COIL 1 PAVCCZ
L4952 G1C220MA0533 COIL 1 PAVCCZ
L5300 G1C220MA0445 COIL 1 PAVCCZ
L5400 G1C4R7ZA0311 COIL 1 PAVCCZ
L5440 G1C4R7MA0445 COIL 1 PAVCCZ
L5700 G1C2R2MA0464 COIL 1 PAVCCZ
L6704 J0JYC0000464 FILTER 1 PAVCCZ
L6706 J0JYC0000464 FILTER 1 PAVCCZ
L6800 J0JYC0000464 FILTER 1 PAVCCZ
L6801 J0JYC0000464 FILTER 1 PAVCCZ
L6802 J0JYC0000464 FILTER 1 PAVCCZ
L7201 J0JKB0000034 FILTER 1 PAVCCZ
L7202 J0JKB0000034 FILTER 1 PAVCCZ
L7207 J0JHC0000075 FILTER 1 PAVCCZ
L7502 G0C270MA0049 COIL 1 PAVCCZ
L8100 G1C3R3MA0464 COIL 1 PAVCCZ
L8101 G1C1R5ZA0311 COIL 1 PAVCCZ
L8602 J0ZZB0000142 FILTER 1 PAVCCZ
L8605 J0JYC0000464 FILTER 1 PAVCCZ
L8615 J0ZZB0000142 FILTER 1 PAVCCZ
L8616 J0ZZB0000142 FILTER 1 PAVCCZ
L8617 J0JYC0000464 FILTER 1 PAVCCZ
L8618 J0JYC0000464 FILTER 1 PAVCCZ
L8660 J0JBC0000115 FILTER 1 PAVCCZ
L8662 J0JHC0000045 FILTER 1 PAVCCZ
L8663 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
L8751 J0JYC0000464 FILTER 1 PAVCCZ
LF7103 G0B153G00003 LINE FILTER 1 PAVCCZ
LF7104 G0B153G00003 LINE FILTER 1 PAVCCZ
LF7105 G0B350HA0036 LINE FILTER 1 PAVCCZ
P2 K1KY14BA0386 14P CONNECTOR 1 PAVCCZ
P4 K1KY12BA0400 12P CONNECTOR 1 PAVCCZ
PA4900 K5H1022A0031 FUSE 1 PAVCCZ
PA7403 K5G103AA0009 FUSE 1 PAVCCZ
PA7406 ERBRE5R00V FUSE 1 PAVCCZ
PC7301 B3PAA0000629 PHOTO COUPLER 1 PAVCCZ
PC7302 B3PAA0000629 PHOTO COUPLER 1 PAVCCZ
PC7303 B3PAA0000629 PHOTO COUPLER 1 PAVCCZ
Q2012 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q2013 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q3301 B1ABCE000015 TRANSISTOR 1 PAVCCZ
Q3302 B1ABCE000015 TRANSISTOR 1 PAVCCZ
