Self Check
How to access
Self-check indication only:
While pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control.
Self-check indication and forced to factory shipment setting:
While pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote control for more than 3 seconds.
How to exit
Switch off the power with the [POWER] button on the main unit.
Display Ref. No. Description P.C.B.
H14TUN TU6705 TUNER A-Board
H90STBY IC8000 IC Peaks-Paragon A-Board
H91MEM2 IC8900 Flash Memory A-Board
H17LAN IC8900 MAC A-Board
H00FE IC6800 DVB-T/T2/C Demodulator A-Board
H96ID IC8900 CI+, DTCP-IP A-Board
H97ID2 IC8900 Netflix, Widewine, HDCP A-Board
H42WiFi
IC8000
N5HBZ0000101
IC Peaks-Paragon
WIFI DONGLE
A-Board
Wifi Dongle
H21DSP IC4900 Audio Amplifier with DSP A-Board
If the CCU
p
orts have been checked and found to be incorrect or not located then " - - " will a
pp
ear in
p
lace of "O.K.".
TX-L42ET60B
42FHD
Self Check Com
p
lete
H14TUN O.K.
H90STBY O.K.
H91MEM2 O.K.
H17LAN O.K.
H00FE O.K.
H96ID O.K.
H97ID2 O.K.
H42WiFi O.K.
H21DSP O.K.
PEAKS-SOFT 3.669
PEAKS-EEP 01.02.0081
LSI-PACKAGE 0.023
LSI-RELEASE 1.08
STBY-SOFT 1.01.02
STBY-EEP 1.00.315d
MODEL ID 0A
03000140
00000200
TX-L42ET60Y
42FHD
Self Check Com
p
lete
H14TUN O.K.
H90STBY O.K.
H91MEM2 O.K.
H17LAN O.K.
H00FE O.K.
H96ID O.K.
H97ID2 O.K.
H42WiFi O.K.
H21DSP O.K.
PEAKS-SOFT 3.669
PEAKS-EEP 01.02.0044
LSI-PACKAGE 0.023
LSI-RELEASE 1.08
STBY-SOFT 1.01.02
STBY-EEP 1.00.315d
MODEL ID 0A
03000143
00000200
TX-LR42ET60
42FHD
Self Check Com
p
lete
H14TUN O.K.
H90STBY O.K.
H91MEM2 O.K.
H17LAN O.K.
H00FE O.K.
H96ID O.K.
H97ID2 O.K.
H42WiFi O.K.
H21DSP O.K.
PEAKS-SOFT 3.669
PEAKS-EEP 01.02.0063
LSI-PACKAGE 0.023
LSI-RELEASE 1.08
STBY-SOFT 1.01.02
STBY-EEP 1.00.315d
MODEL ID 0A
03000145
00000200
21
