Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
C8233 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8234 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8236 F1H0J4750004 C 4700NF, , 6.3V 1 PAVCCZ
C8237 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C8246 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8248 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8249 F1G1H1020008 C 1NF, , 50V 1 PAVCCZ
C8250 F1G1H1020008 C 1NF, , 50V 1 PAVCCZ
C8251 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8252 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8253 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8254 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8255 F1J0G2260001 C 22UF, , 4V 1 PAVCCZ
C8300 F1G1H8R0A831 C 8PF, , 50V 1 PAVCCZ
C8301 F1G1H8R0A831 C 8PF, , 50V 1 PAVCCZ
C8400 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8401 F1J0J2260004 C 22UF, , 6.3V 1 PAVCCZ
C8402 F1J0J2260004 C 22UF, , 6.3V 1 PAVCCZ
C8404 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8405 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8600 F1L3D1020008 C 1NF, , 2KV 1 PAVCCZ
C8601 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C8602 F1G1C1030008 C 10NF, , 16V 1 PAVCCZ
C8613 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8615 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8642 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8643 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8660 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8661 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8668 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8669 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8670 F1J0G2260001 C 22UF, , 4V 1 PAVCCZ
C8671 F1G1H220A834 C 22PF, , 50V 1 PAVCCZ
C8672 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8673 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8674 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C8675 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8680 EEEHB0J221UP E 220UF, , 6.3V 1 PAVCCZ
C8681 EEEHB0J221UP E 220UF, , 6.3V 1 PAVCCZ
C8682 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8683 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8687 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8688 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8689 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8690 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8692 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8693 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8757 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8758 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8760 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8761 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8764 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
C8765 F1H0J4750004 C 4700NF, , 6.3V 1 PAVCCZ
C8850 F1H0J4750004 C 4700NF, , 6.3V 1 PAVCCZ
C8851 F1H0J4750004 C 4700NF, , 6.3V 1 PAVCCZ
C8902 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8903 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
CF7101 D4CAY2R20002 NTC THERMISTOR 1 PAVCCZ
CN0100 K1KA14A00248 14P CONNECTOR 1 PAVCCZ
36
