Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
R2852 D1BD1911A177 M 1K91 OHM, F, 1/8W 1 PAVCCZ
R2853 D1BD3091A177 M 3K09 OHM, F, 1/8W 1 PAVCCZ
R2854 D1BD6041A076 M 6K04 OHM, F, 1/8W 1 PAVCCZ
R2855 D1BD1692A177 M 16K9 OHM, F, 1/8W 1 PAVCCZ
R3002 D1BD2200A066 M 220 OHM, F, 1/8W 1 PAVCCZ
R3007 D1H81014A042 M 100 OHM, J, 1/16W 1 PAVCCZ
R3008 D1BD18R0A179 M 18 OHM, F, 1/8W 1 PAVCCZ
R3009 D1BD18R0A179 M 18 OHM, F, 1/8W 1 PAVCCZ
R3010 D1BD18R0A179 M 18 OHM, F, 1/8W 1 PAVCCZ
R3011 D0GA100JA023 M 10 OHM, J, 1/16W 1 PAVCCZ
R3012 D1BD56R0A179 M 56 OHM, F, 1/8W 1 PAVCCZ
R3013 D1BD56R0A179 M 56 OHM, F, 1/8W 1 PAVCCZ
R3014 D1BD56R0A179 M 56 OHM, F, 1/8W 1 PAVCCZ
R3015 D1H81014A042 M 100 OHM, J, 1/16W 1 PAVCCZ
R3038 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3041 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R3042 D1BF75R0A073 M 75 OHM, F, 1/4W 1 PAVCCZ
R3043 D1BF75R0A073 M 75 OHM, F, 1/4W 1 PAVCCZ
R3044 D1BF75R0A073 M 75 OHM, F, 1/4W 1 PAVCCZ
R3045 D1BF75R0A073 M 75 OHM, F, 1/4W 1 PAVCCZ
R3047 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R3052 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3053 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R3054 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R3055 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3056 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3058 D0GA330JA023 M 33 OHM, J, 1/16W 1 PAVCCZ
R3061 D0GA513JA023 M 51K OHM, J, 1/16W 1 PAVCCZ
R3063 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R3064 D0GAR00J0005 M 0 OHM, J, 1/16W 1 PAVCCZ
R3121 D0GA101JA039 M 100 OHM, J, 1/16W 1 PAVCCZ
R3167 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R3168 D0GA333JA023 M 33K OHM, J, 1/16W 1 PAVCCZ
R3202 D1BF75R0A073 M 75 OHM, F, 1/4W 1 PAVCCZ
R3301 D1BA6802A023 M 68K OHM, F, 1/16W 1 PAVCCZ
R3302 D1BA6802A023 M 68K OHM, F, 1/16W 1 PAVCCZ
R3303 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3304 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R3305 D1BA2002A023 M 20K OHM, F, 1/16W 1 PAVCCZ
R3306 D1BA2002A023 M 20K OHM, F, 1/16W 1 PAVCCZ
R3307 D1BA5602A023 M 56K OHM, F, 1/16W 1 PAVCCZ
R3308 D1BA5602A023 M 56K OHM, F, 1/16W 1 PAVCCZ
R3309 D0GA331JA023 M 330 OHM, J, 1/16W 1 PAVCCZ
R3310 D0GA331JA023 M 330 OHM, J, 1/16W 1 PAVCCZ
R3313 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R3314 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R3315 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R3316 D0GA332JA023 M 3K3 OHM, J, 1/16W 1 PAVCCZ
R3317 D0GA104JA039 M 100K OHM, J, 1/16W 1 PAVCCZ
R3318 D0GA104JA039 M 100K OHM, J, 1/16W 1 PAVCCZ
R3319 D0GB332JA065 M 3K3 OHM, J, 1/10W 1 PAVCCZ
R3320 D0GB332JA065 M 3K3 OHM, J, 1/10W 1 PAVCCZ
R3324 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R3325 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4004 D0GA243JA023 M 24K OHM, J, 1/16W 1 PAVCCZ
R4700 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4701 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4702 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4703 D0GA103JA039 M 10K OHM, J, 1/16W 1 PAVCCZ
R4704 D0GA473JA039 M 47K OHM, J, 1/16W 1 PAVCCZ
R4705 D0GA102JA039 M 1K OHM, J, 1/16W 1 PAVCCZ
R4706 D0GA220JA023 M 22 OHM, J, 1/16W 1 PAVCCZ
41
