Option Bytes Description
OPTION1
b1 TEXT Ch Refresh ON (1) / OFF (0)
b2 ID-1 ON (1) / OFF (0)
b3 Macrovision Auto-judge ON (1) / OFF (0)
b4 “BassBoost” sound menu enable ON (1) / OFF (0)
b5 “Digital Remaster” sound menu enable ON (1) / OFF (0)
b6 Enable HDMI force reset ON (1) / OFF (0)
b7 TINT_Component_HDMI ON (1) / OFF (0)
OPTION2
b0 Adjust gain enable ON (1) / OFF (0)
b1 A2 BG enable (5.5MHz) ON (1) / OFF (0)
b2 A2 DK1 enable (6.26MHz) ON (1) / OFF (0)
b3 A2 DK3 enable (5.742MHz) ON (1) / OFF (0)
b4 NICAM scan ON (1) / OFF (0)
b5 NICAM BG enable (5.5MHz) ON (1) / OFF (0)
b6 NICAM I enable (6.0MHz) ON (1) / OFF (0)
b7 NICAM DK enable (6.5MHz) ON (1) / OFF (0)
OPTION3
b0 NICAM priority ON (1) / OFF (0)
b1 Starhub scan enable (Singapore) ON (1) / OFF (0)
b2
Enable special edge smoother function
(CHINA)
ON (1) / OFF (0)
b3 A2 DK2 enable ON (1) / OFF (0)
b4
Inhibition of countermeasure
for SIF signal drop
ON (1) / OFF (0)
b5 Get onid from physical CH (CHINA) ON (1) / OFF (0)
b6 SSU search enable for HOTEL model ON (1) / OFF (0)
b7 SASO mute (ASIA) ON (1) / OFF (0)
OPTION4
b2 3DYC color motion detect ON (1) / OFF (0)
b3 RF Clamp Current minimum (TAIWAN) ON (1) / OFF (0)
b4 SHOP banner enable ON (1) / OFF (0)
b5
Enable LGD panel problem soft
countermeasure
ON (0) / OFF (1)
b6 PIP ON (1) / OFF (0)
b7
Enable workaround for Polsat CAM
problem (POLAND)
ON (1) / OFF (0)
20
