Model No. : TX-L42ET60B+Y+LR Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
C6840 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C6844 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C6847 F1G1H8R0A833 C 8PF, -, 50V 1 PAVCCZ
C6848 F1G1H8R0A833 C 8PF, -, 50V 1 PAVCCZ
C6864 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C6872 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C6873 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C7102 F1AAF471A019 C 470PF, K, 250V 1 PAVCCZ
C7103 F1AAF471A019 C 470PF, K, 250V 1 PAVCCZ
C7104 F0CAF2240010 P 0.22UF, K, 250V 1 PAVCCZ
C7105 F0CAF2240010 P 0.22UF, K, 250V 1 PAVCCZ
C7201 F1J1H102A909 C 1NF, , 50V 1 PAVCCZ
C7202 F1J1H222A911 C 2200PF, , 50V 1 PAVCCZ
C7203 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7204 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7205 F1J1H102A909 C 1NF, , 50V 1 PAVCCZ
C7206 F1J1E475A257 C 4700NF, , 25V 1 PAVCCZ
C7207 F1A3A101A060 C 100PF, , 1KV 1 PAVCCZ
C7208 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7209 ECWFD2W824KC P 0.82UF, K, 450V 1 PAVCCZ
C7210 ECWFD2W824KC P 0.82UF, K, 450V 1 PAVCCZ
C7213 F2A2W7700001 E 77UF, M, 450V 1 PAVCCZ
C7214 F1J1H103A900 C 10NF, , 50V 1 PAVCCZ
C7220 F1J1H472A900 C 4.7NF, , 50V 1 PAVCCZ
C7302 F1J1H473A900 C 0.047UF, -, 50V 1 PAVCCZ
C7303 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7304 F1A3A221A060 C 220PF, , 1KV 1 PAVCCZ
C7305 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7306 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C7307 F1J1H101A906 C 100PF, , 50V 1 PAVCCZ
C7310 F2A1E4710124 E 470UF, M, 25V 1 PAVCCZ
C7311 F1J1E105A287 C 1000NF, , 25V 1 PAVCCZ
C7312 F1H1C474A178 C 470NF, , 16V 1 PAVCCZ
C7313 F1J1H102A909 C 1NF, , 50V 1 PAVCCZ
C7315 F1A3A221A060 C 220PF, , 1KV 1 PAVCCZ
C7316 F1A3A221A060 C 220PF, , 1KV 1 PAVCCZ
C7317 ECWH8223HAC P 0.022UF, , 800V 1 PAVCCZ
C7318 F1AAF471A019 C 470PF, K, 250V 1 PAVCCZ
C7416 F1J1C475A225 C 4700NF, , 16V 1 PAVCCZ
C7417 F1H1C474A178 C 470NF, , 16V 1 PAVCCZ
C7418 F1H1H104B047 C 100NF, , 50V 1 PAVCCZ
C7421 F1H1H104B047 C 100NF, , 50V 1 PAVCCZ
C7422 F2A1V6810043 E 680UF, M, 35V 1 PAVCCZ
C7423 F2A1E222B927 E 2200UF, , 25V 1 PAVCCZ
C7434 F1J1C475A225 C 4700NF, , 16V 1 PAVCCZ
C7436 F1J1C475A225 C 4700NF, , 16V 1 PAVCCZ
C7520 F1J1E105A287 C 1000NF, , 25V 1 PAVCCZ
C7521 F1J1E105A287 C 1000NF, , 25V 1 PAVCCZ
C7522 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C7523 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C7524 F1J1H472A900 C 4.7NF, , 50V 1 PAVCCZ
C7525 F1J1H223A900 C 22NF, , 50V 1 PAVCCZ
C7526 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C7527 F1K1V106A010 C 10UF, , 35V 1 PAVCCZ
C7529 F1J1H104A902 C 100NF, , 50V 1 PAVCCZ
C8002 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8007 F1J0G2260001 C 22UF, , 4V 1 PAVCCZ
C8008 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8012 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8013 F1G1C104A077 C 100NF, , 16V 1 PAVCCZ
C8014 F1J1A106A087 C 10UF, , 10V 1 PAVCCZ
C8015 F1G1A105A047 C 1000NF, , 10V 1 PAVCCZ
34
