Multi Color Jet
BEFORE OPERATION
14/09/2011 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 12 / 64
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
3 BEFORE OPERATION
3.1 Unpacking
You receive your Trotec Multi Color Jet packed in a wooden box, which contains the machine and
additional accessories. The following steps give you an overview of the unpacking and assembly of
the laser. Please follow these steps carefully.
Keep the packing box. You will require it in case of a return.
Dispose all waste according to the applicable waste disposal law.
Remove the cover. Please do not forget to store this box in a dry place.
Carefully remove the foam material, which protects the viewing window of the cover, and the tape
that holds this cover in place.
Lift the machine out of the box. For this you will require two persons. Position the machine on a
stable table or on the delivered trolley (optional).
3.2 Contents of Delivery
Transport and service packaging
Multi Color Jet
Flexible Tray including all Trodat MCI compatible pad frames
15 ink tanks
15 Dispenser
Stand (optional)
Accessories:
1. TROTEC installation DVD including software and operation manual
2. Mains cable
3. Computer connection cable USB
1
2
3
