![Trotec Multi-Color-Jet [7/64] Technical data device specification](/views2/1404720/page7/bg7.png)
Multi Color Jet
GENERAL
14/09/2011 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 7 / 64
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
1.4 Technical Data / Device Specification
Technical Data
Mechanic
Working area Max. 4 pads x 3 pads
Motor Stepper motor
Specifications
Ink capacity 15 tanks, each 150ml
Pad capacity Max. 12 individual Trodat Multi Color pads
Design preconditions Color field size min. 8 x 8 mm
Distance between color fields min. 2.5 mm
Compatible Trodat stamps /
ink cartridges (pads)
Stamps for the office: Trodat Professional
Stamps for at home and on the move: Trodat Printy and
Trodat Mobile Printy
Compatible Trotec Lasers Speedy 100 / 100R; Speedy 300; Rayjet
Option Trolley base
Control system
Interface Hardware USB
Electricity, Power, Fuse
Voltage Single phase 100-250V 50/60Hz
Power consumption 300W
Current consumption 2 A (230V) 4 A (115V)
Recommended fuse 10A (230V / 115V)
Dimensions
Width/depth/height (approx.) 28.4 x 29 x 20” / 720 x 735 x 500 mm
Weight (approx.) 99 lbs / 45 kg
Ambient conditions
Temperature 59°F to 77°F / +15°C to +25°C
Humidity 40% to max 70%, not condensing
Safety
Interlock Duplicate interlock safety system
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
JANUARY 2011
