Multi Color Jet
ADDITIONAL INFORMATION
14/09/2011 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 64 / 64
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
6.7 Response Form
If you face any troubles with the machine, please provide the following information.
Date
Machine Details
Contact Details
Serial number Name
Software Version
Laser
Country
Software Version
Multi Color Jet
Phone Number
Driver Version Email address
Layout Software
Firmware Version
Problem Description
Does an Error message show up on the PC, if so which one?
What happened before the error showed up? (Thunderstorm, Windows-Update…)
What was tried to solve the problem?
Please send the information to your sales representative or to techsupport@troteclaser.com
.
