4.6.5 Control Buttons
Connect – click on this icon to connect the computer with the Multi Color Jet.
After pressing this button it switches to …
Start – click this button to start the inking of the currently marked tray or pad.
When the Multicolor Jet is turned off while the software is running, the “Start” icon
switches back to the “Connect” view.
Delete – click on this icon to delete the currently marked trays.
When the software is shut down, all produced trays will be deleted automatically.
Ink Tank Configuration – click on this icon to get access to the “ink tank
configuration” dialogue where you can check the status of ink tanks and start
procedures like exchanging, removing or adding ink tanks.
