Multi Color Jet
BEFORE OPERATION
14/09/2011 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 19 / 64
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com
3.7.2 Connecting the Computer
Before you connect the Multi Color Jet to the computer, both systems must
be switched off and connected to the mains voltage.
All software has to be installed prior to connecting the machine with the PC!
Connect the USB cable to the USB port on the device (12) and plug it to a free USB port
on your computer.
12
