Multi Color Jet

OPERATION

14/09/2011 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 21 / 64

tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, mailto: techsupport@troteclaser.com

Number Name Description

1 Dispenser The dispensers are responsible for the exact dosage of the ink.

2 X-axis The x-axis is carrying the dispenser unit.

3 Top lid If the top lid is opened, no moves will be performed. After closing

the Top lid, the device is not ready to process commands for 5

seconds.

If the top lid is opened during operation, the motion system is

stopped. The job cannot be continued. Please cut a new pad and

ink it with the new generated ink job.

Never rest on the top lid or use it as support! This might

lead to misalignment of the system.

4 Dispenser unit The dispenser unit is carrying the dispensers and transfers the

color from the ink tanks to the multi color pads.

5 Ink tanks The ink tanks can easily be exchanged. Please follow the tank

change procedure if the current tank turns to have not enough

ink for a new pad inking procedure.

Never refill used tanks. Always order new original Trodat /

Trotec Multi Color tanks due to safety and quality reasons.

6 Start / Stop

buttons

Pressing the green “Start” button starts the job which is currently

visible in the Multi Color Jet software.

If the red “Stop” button is pressed during operation, the motion

system is stopped. The job cannot be continued. Please cut a

new pad and ink it with the new generated ink job.

7 Manufacturers

label

Shows important data of the machine like serial number and

manufacturing date.

8 On/off switch Use this switch to turn the machine on/off.

9 Power socket To connect the main power according the information on the

manufacturers label. In the Power Socket are the fuses.

10 Power supply Changes the main power to power types suitable for the

mechanic and electronic parts of the machine.

11 Electronics The electronics are situated under the electronics cover.

12 PC connection

cable (USB)

At this socket the USB connection cable has to be plugged in.
