TL-MR3020 Portable 3G/4G Wireless N Router

 Standard AP - In this mode, the device enables multiusers to access, and provides several

, Client, R

G Router - In this mode, the device ena

bles multiusers to share Internet via

ADSL/Cable Modem. The wireless port share the same IP to ISP through Ethernet WAN

port. The Wireless port acts the same as a LAN port while at 3G/4G Router mode.

 WISP Client Router - In this mode, the device enables multiusers to share Internet from

WISP. The LAN port devices share the same IP from WISP through Wireless port. While

connecting to WISP, the Wireless port works as a WAN port at WISP Client Router mode.

The Ethernet port acts as a LAN port.



Note:

The router will reboot automatically after you click the Save button.

5.16.10 Statistics

Choose menu “System Tools → Statistics”, and then you can view the statistics of the Router,

including total traffic and current traffic of Interval.

wireless modes, su

ch as AP epeater and so on.

 3G/4

the last Packets Statistic

Figure 5-89 Statistics

Enable or Disable. The default value is disabled. To enable Current Statistics Status - it,

click the Enable button. If it is disabled, the function of DoS protection in Security settings

will be disabled.

 Packets Statistics Interval （5-60） - The default value is 10. Select a value between 5

and 60 seconds in the drop-down list. The Packets Statistic interval indicates the time

section of the packets statistic.

 Sorted Rules - Choose how the displayed statistics are sorted.

Select the Auto-refresh checkbox to refresh automatically.

-186-
