Tp-Link TL-MR3020 [86/258] Remote management

TL-MR3020 Portable 3G/4G Wireless N Router

After click the Add button, your PC's MAC Address will be placed in the list above.

Click the Save button to save your settings.



Note:

If your PC is blocked but you want to access the Router again, press and hold the Reset

Button on the front panel for at least 10 seconds to reset the Router’s factory defaults on the

Router’s Web-Based Utility.

4.9.4 Remote Management

Choose menu “Security → Remote Management”, you can configure the Remote

Management function in the screen as shown in Figure 4-48. This feature allows you to manage

your R

outer from a remote location via the Internet.

Figure 4-48 Remote Management

 Web Management Port - Web browser access normally uses the standard HTTP service

port 80. This Router's default remote management web port number is 80. For greater

security, you can change the remote management web port to a custom port by entering

that number in the box provided. Choose a number between 1 and 65534 but do not use

the number of any common service port.

 Remote Management IP Address - This is the current address you will use when

accessing your Router from the Internet. This function is disabled when the IP address is

set to the default value of 0.0.0.0. To enable this function change 0.0.0.0 to a valid IP

address. If set to 255.255.255.255, then all the hosts can access the Router from internet.



Note:

1) To access the Router, you should type your Router's WAN IP address into your browser's

address (in IE) or Location (in Navigator) box, followed by a colon and the custom port

number. For example, if your Router's WAN address is 202.96.12.8, and the port number

used is 8080, please enter http://202.96.12.8:8080 in your browser. Later, you may be

asked for the Router's password. After successfully entering the username and password,

you will be able to access the Router's web-based utility.

2) Be sure to change the Router's default password to a very secure password.

-75-
