TL-MR3020 Portable 3G/4G Wireless N Router

 MAC Address - Here displays the MAC address of the DHCP client.

 Assigned IP - Here displays the IP address that the AP has allocated to the DHCP client.

update this page and to show the current

attached devices, click on the Refresh button.

so the PC will always obtain the same IP address each time when it accesses

the AP. Reserved IP addresses should be assigned to servers that require permanent IP

 Lease T

ime - Here displays the time of the DHCP client leased. Before the time is up, DHCP

client will request to renew the lease automatically.

You cannot change any of the values on this page. To

6.7.3 Address Reservation

Selecting DHCP > Address Reservation will enable you to specify a reserved IP address for a

PC on the LAN,

settings. The screen below is used for address reservation (shown in Figure 6-22).

Figure 6-22 Address Reservation

 Status - Here shows whether the entry is enabled or not

an existing entry.

2. Enter the MAC address in XX-XX-XX-XX-XX-XX format and IP address in dotted-decimal

notation of the computer you wish to add.

3. Click Save when finished.

To modify A Reserved IP address:

1. Select the reserved address entry to your needs and click Modify. If you wish to delete the

entry, click Delete.

2. Click Save to keep your cha

 MAC Address - Here displays the MAC address of the PC for which you want to reserve an

IP address.

 Reserved IP Address - Here displays the IP address that the AP is reserved.

 Modify - To modify or delete

To Reserve IP addresses:

1. Click the Add New... button to add a new Address Reservation entry.

nges.

To delete all Reserved IP addresses:

1. Click Clear All.

-221-
