TL-MR3020 Portable 3G/4G Wireless N Router

11n only - Select if all of your wireless clients are 802.11n.

11bg mixed - Select if you are using both 802.11b and 802.11g wireless clients.

11bgn mixed - Select if you are using a mix of 802.11b, 11g, and 11n wireless clients.

Select the desired wireless mode. When 802.11g mode is selected, only 802.11g wireless

stations can connect to the Router. When 802.11n mode is selected, only 802.11n

wireless stations can connect to the AP. It is strongly recommended that you set the Mode

to 802.11b&g&n, and all of 802.11b, 802.11g, and 802.11n wireless stations can connect

to the Router.

 Channel width - Select any channel width from the pull-down list. The default setting is

automatic, which can adjust the channel width for your clients automatically.



Note:

If 11b only, 11g only, or 11bg mixed is selected in the Mode field, the Channel Width

selecting field will turn grey and the value will become 20M, which is unable to be changed.

 Max Tx Rate - You can limit the maximum tx rate of the Router through this field.

 Enable Wireless Router Radio - The wireless radio of this Router can be enabled or

disabled to allow wireless stations access.

 Enable SSID Broadcast - When wireless clients survey the local area for wireless networks

to associate with, they will detect the SSID broadcast by the Router. If you select the Enable

SSID Broadcast checkbox, the Wireless Router will broadcast its name (SSID) on the air.

 Enable WDS Bridging - Check this box to enable WDS Bridging. With this function, the

Router can bridge two or more WLANs. If this checkbox is selected, you will have to set the

following parameters as shown below. Make sure the following settings are correct

 SSID(to be bridged) - The SSID of the AP your Router is going to connect to as a

client. You can also use the search function to select the SSID to join.

 BSSID(to be bridged) - The BSSID of the AP your Router is going to connect to as a

client. You can also use the search function to select the BSSID to join.

 Survey - Click this button, you can search the AP which runs in the current channel.

 Key type - This option should be chosen according to the AP's security configuration.

It is recommended that the security type is the same as your AP's security type.

-54-
