English
12
○ Ensure that the cutting attachment does not rotate while
the engine is idling. If it does rotate, adjust the idle speed
according to the instructions in “Idle speed adjustment” in
the “MAINTENANCE” section. If the cutting attachment
still rotates after this adjustment, immediately stop the
engine and cease use, then bring the tool to the nearest
HiKOKI Authorized Service Center.
CAUTION
For the CG24ECP / CG27EC / CG27ECP, ensure that
the throttle outer end is in the holder.
(1) Starting the cold engine
1. Set ignition switch (27) to ON position. (Fig. 18)
2. Push priming bulb (28) about ten times so that fuel fl ows
into carburetor. (Fig. 19)
3. Set choke lever (30) to START position (closed) (A).
(Fig. 20)
4. Pull recoil starter briskly, taking care to keep the handle
in your grasp and not allowing it to snap back. (Fig. 21)
5. When you hear the engine want to start, return choke
lever to RUN position (open) (B). (Fig. 20)
6. Pull recoil starter briskly again. (Fig. 21)
NOTE
If engine does not start, repeat procedures from 2 to 5.
7. Then allow the engine about 2–3 minutes to warm up
before subjecting it to any load.
8. Check that the cutting attachment does not rotate when
the engine is idling.
(2) Starting the warm engine
Use only 1, 2, 6 and 8 of the starting procedure for a cold
engine.
If the engine does not start, use the same starting
procedure as for a cold engine.
Cutting
WARNING
○ Always use the harness (if so equipped) and wear the
proper attire and protective equipment when operating
the unit. (Fig. 22)
○ Keep others including children, animals, bystanders and
helpers outside the 15 m hazard zone. Stop the engine
immediately if you are approached. (Fig. 23)
○ When grass or vines wrap around attachment, stop
engine and attachment and remove them. Continuing
operation with grass or vines wrapped around the
attachment may result in damages such as early
abrasion of the clutch.
CAUTION
Use and points of caution will vary depending on the type
of cutting attachment. For safe use, make sure to follow
the instructions and guidelines provided with each type.
NOTE
○ Press the quick release button or pull emergency release
fl ap (If so equipped) in the event of emergency. (Fig. 24)
○ Use in accordance with local laws and regulations.
CG24ECMP/CG27ECMP only
● Governor mechanism
The tool is equipped with a feature that keeps the engine
rotation speed consistent at the speed that is set. This
maintains a stable engine rotation speed even when the
burden applied to the tool bit becomes large, allowing for
steady operation.
However, if a burden larger than the tolerance is applied,
the engine rotation will decrease; in this case, adjust the
burden by decreasing the amount of material being cut.
The governor mechanism does not function when the
throttle is fully open.
(1) Using a semi-auto cutting head
○ Set the engine at high speed when using this attachment.
○ Cut grass from left to right. The cut grass will be
discharged away from the body, minimizing transfer to
your clothes. (Fig. 25)
○ With nylon cord, use about 2 cm of the end of the cord
to cut grass. Using the full length of the cord will reduce
rotation speed and make cutting diffi cult.
NOTE
Automatically feeds more nylon cutting line when it is
tapped at low rpm (not greater than 4500 min
-1
).
WARNING
○ This product is equipped with a line limiter that will
automatically cut any excess cord. When operating the
unit, do not remove the guard or line limiter.
As the resistance is greater for nylon cords as opposed
to blades, mishandling could increase engine load and
result in damage.
○ Do not use with the engine set at low speeds. If the
engine speed is low, grass may wrap around the
attachment, causing the clutch to slip which could result
in clutch abrasion.
○ With nylon cord cutters, always use over 15 cm of cord.
If the length of the cord is too short, rotation speed will
increase and may cause damage to the nylon cord
cutter. As the curved drive shaft tube model in particular
is not equipped with a deceleration mechanism, the
possibility of increased rotation speed for the cutting
attachment is high.
(2) Using a blade
○ Adjust engine speed according to the resistance of the
grass. For soft grass, use low speeds, For tough clumps
of grass, use high speeds.
○ Cut grass from right to left, using the left side of the blade
to cut. (Fig. 26)
○ Slightly tilting the blade to the left while cutting will pile
the cut grass to the left, making collection easy.
NOTE
Excessively increasing rotation speed may cause
increased blade wear, vibration and noise. It will also
result in increased fuel consumption.
WARNING
○ Blade thrust may occur when the spinning blade contacts
a solid object in the critical area.
A dangerous reaction may occur causing the entire unit
and operator to be thrust violently. This reaction is called
blade thrust. As a result, the operator may lose control
of the unit which may cause serious or fatal injury. Blade
thrust is more likely to occur in areas where it is diffi cult
to see the material to be cut.
○ If cutting attachment should strike against stones or
other debris, stop the engine and make sure that the
attachment and related parts are undamaged.
Stopping (Fig. 27)
Decrease engine speed and run at an idle for a few minutes,
then turn off ignition switch (27).
WARNING
A cutting attachment can injure while it continues to spin
after the engine is stopped or power control is released.
When the unit is turned off , make sure the cutting
attachment has stopped before the unit is set down.
Throttle adjustment knob (Fig. 28)
The cutting blade speed setting for when the throttle trigger
is fully pulled can be adjusted.
To increase the speed setting, turn the throttle adjustment
knob (31) clockwise, and to decrease the speed setting, turn
the knob counter-clockwise.
000Book_CG24ECP(S).indb 12000Book_CG24ECP(S).indb 12 2017/12/14 9:49:522017/12/14 9:49:52
