EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 27
6.1.2 Parameter configuration in frequency converter (using FU-Control)
Parameter configuration can commence after the converter has completed reading the parameters.
The appropriate menu items are selected using the raise/lower buttons and activated
for editing using the right button. The editing sequence can be selected freely.
Editing: Position the cursor at the appropriate position using the move right or move
left button
A numerical or algebraic sign change can be made using the up or down buttons.
Accept altered values: Operate the right button until FU-Control reports "VALUE
ACCEPTED".
The possible min/max values can be found in Chapter 8.1: Parameter overview.
Distinctive number: Factory setting "0": no password request.
A lost password can be altered only using EmoSoftLift or by our service staff.
Select menu item "Save values"
After this menu item has been selected and activated using the right button, the following appears in the
display:
Please wait
Do not switch off
(after approx. 10 seconds)
Please wait...
Software reset
The value is "valid" for the frequency converter only after saving.
Do not read, alter or save data while the lift is moving
6.1.2.1 Run lift
Please take note of Chapter TIPS, TRICKS AND TOUBLESHOOTING.
6.1.2.2 Fine adjustment of the lift
Please take note of Chapter TIPS, TRICKS AND TOUBLESHOOTING and the remarks in Chapter
PARAMETERS AND VARIABLESLIST.
6.1.2.3 Fault and event memory
This memory records the last 100 trips or approx. 1000 messages. If the events (status) are not to be
displayed, then the address 0F06h can be selected beforehand in the menu "Change address": if its content
is set to 00255, then only faults will be displayed. All events will be displayed if the setting is 0000. The
memory can also be read there from EmoSoftLift and higher.
A RAM memory is used, so please do not disconnect the device from the mains supply (this
deletes the memory).
6.1.2.4 Password
All FU-Controls (that means internal and external FU-Controls for system DSV 5445) provide since March
2001 password protection with factory setting “0” (0 = no password required). If the password protection is
activated with a numeric input between ±2.000.000.000 the control panel requires this input to modify
parameters or variables. Attention: A lost password can only be deleted with the program EmoSoftLift. In this
case you can call our hotline for deleting the code addresses.
