EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 35
7.2 Current firmware
The employed firmware can be determined from the following list.
7.2.1 40 MHz – TUDYxxN or 50 MHz - TUDXxxN for all standard lift-winches
Serie = 30 ≡
≡≡
≡ TUDYX3N/XX3N for DSV 544x-Typen with 16A, 20A, 40A, 120A, 150A, 200A
Serie = 40 ≡
≡≡
≡ TUDY04N/X04N for DSV 544x-Typen with 5A, 9.2A, 10A, 60A, 80A, 250A
Serie = 43 ≡
≡≡
≡ TUDYX4N/XX4N for DSV 544x-Typen with 30A, 60A, 150A (old)
Serie = 48 ≡
≡≡
≡ TUDY05N/X05N for DSV 544x-Typen with 15A, 70A
7.2.2 50 MHz – TUDZxxN - Reglerkarte for all gearless- or ’Alpha’-winches
Serie = 30 ≡
≡≡
≡ TUDZX3N for DSV 544x-Typen with 20A (old), 150A, 200A
Serie = 40 ≡
≡≡
≡ TUDZ04N for DSV 544x-Typen with 5A, 10A, 60A (old), 80A (old), 250A
Serie = 43 ≡
≡≡
≡ TUDZX4N for DSV 544x-Typen with 30A, 150A (old)
Serie = 48 ≡
≡≡
≡ TUDZ05N for DSV 544x-Typen with 15A, 20A
Serie = 60 ≡
≡≡
≡ TUDZ06N for DSV 544x-Typen with 40A, 60A, 120A
Serie = 70 ≡
≡≡
≡ TUDZ07N for DSV 544x-Typen with 70A, 80A
An exchange of firmware EPROM’s may be made only after consultation with our factory,
since "incorrect" versions can lead to functional faults.
The firmware, delivery state, is recorded on the rating plate.
7.2.3 Old device series (20 MHz – DSV 5444 or 20 MHz – DSV 5442)
Please contact our headquarters for the upgrade of older frequency converters for lift systems. "UPD" files
may be available for old devices on the basis of "3SZ" and "7SZ".
7.3 Selection of special lift program versions
7.3.1 Command programs
All programs that are loaded into the converter are known as command programs. They have the ending
.KOM. These programs reset any parameters and variables already modified to the factory settings. (You
must check all parameters and variables after loading a .KOM program and adapt them to your lift system as
applicable).
7.3.2 Update programs
Update programs are all programs with the ending .UPD. The customer parameters are not changed when
these programs are loaded into the converter. (Previous variables and parameters must not be re-entered,
however check the new variables added by the update). The function "Transmit program only" can be
employed under EmoSoftLift instead of using UPD files. New variables/parameters, you can find in the
parameters and variables list, then need values that are still plausible.
