EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 63
10.3.6 Option 2nd encoder ATB
The rotary encoder connection for Heidenhain ERN 1387, ERN 1385 and electrically compatible systems
with 17-pole angled connectors and 15-pole high-density SUB-D male (3-row) on the converter side (screen
attached at both ends):
Plug
type C
15 16 12 13 3 2 14 17 9 8
Housing
7 10 1 4 11
Plug
type F
8 3 9 4 15 14 6 1 7 2
Housing
12 13 --- --- 5
Colour of
wire
green
-
black
yellow
-
black
blue-
black
red-
black
red blac
k
grey pink yell-
ow
pur
-ple
silver brown-
green
white
-
green
blue white blac
k
Descr. K1
A+
K1\
A-
K2
B+
K2\
B-
K0
N+
K0\
N-
K3
C+
K3\
C-
K4
D+
K4\
D-
Outer
screen
5V
Up
0V
Un
5V
sens.
0V
sens.
I-s.
Comm. +sin
2048
-sin
2048
+cos
2048
-cos
2048
+
zero
-
zero
sin
+1
sin
-1
cos
+1
cos
-1
ground
PE
power supply sensor only
if needed
gnd
Synchronous gearless winches with 8-track encoder, i.e. for DSV 5445 with option 2nd encoder
ATB, currently always require the first initialisation described above.
