EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 55
10.1.2 Table of parameters and variables analogue “Beringer” process
Adr Parameter, variable Meaning
Factory
settings
Range of
values
F0
Rotor flow
Motor rotor flux
500 (750) 50...2000
F1
Rated speed
Nominal speed according to rating plate
2905 (1475) 100...4000 1/min
F2
Synchr. speed
Synchronous speed
3000 (1500) 100...4500 1/min
F31
Number of poles
number of motor poles
2 (4) 2...64
i
I-part run
I-part speed controller
300 4...400
k
P-part run
P-part speed controller
300 100...5000
t
Rotor time const.
Motor rotor time constant
100 25...1000
0B34
Version of progr. (>75)
Program revision index (read only)
>75 read only
0E00
Stand. of speed "1"
Evaluation of the analogue set point
(660 = 10 = 3000 1/min)
660 (1452) -1500...1500
0E26
Off-decel. delay
Delay controller switch-off
1 1...1000
0E40
Excess speed "A2"
Speed threshold 1/min for output A2 (0E40 is
also employed for the fixed speed using input
E3 resp. E4; the ramps are stored in 0E64,
analogue in 0E62)
1500 0...4000
0E4A
Encoder pulses (new)
Encoder pulse number
512 (2048) 512, 1024, 2048
0E5A
value of iidt-timer
Unacceptable high current, incorrect rotating
fields and phase angle, and loose encoder lead
to a shut-down of the inverter after the time in
E5A (I²dt error has occurred).
5000 1 - 32767
0E60
Service-flag (emergency
operation)
Emergency operation without encoder
(set rotor flux F0 to maximum)
0 0/255
0E62
Ramp gradient 01
Set ramp flat Y0/Y1
335 (1000) 1...5000
0E64
Ramp gradient 34
Set ramp steep Y0/Y1
67 (67) 1...5000
0E68
Emergency-flag OFF = 0
Flag for switching-off the phase monitoring
("phase failure")
255 0/255
10.1.2.1 Data setting via internal or external FU-Control
The parameters and variables have to be set in the “Beringer” mode. Experienced user only should use other
modes for this, because there were shown either none, wrong or incomprehensible displayed readouts,
according to the chosen mode. The “Beringer” mode always will be set automatically while parameter F29
(hidden) is set to “255”.
10.1.2.2 Setting the data via EmoSoftLift:
In the case of EmoSoftLift, BERINGER.CNF and BERINGER.KOM must be in the corresponding directories
and must be selected to modify the following parameters and variables. Parameter and variables DSV 5445 -
Lift, analogue "Beringer" process.
10.1.2.3
This is the description of the data from BERINGER.KOM or BERIPACK.KOM in the factory setting:
For commissioning you must only check or set the parameters rotor flux F0 and rotor time constant t
according to the "Operating Instructions Messrs Bucher AG" (fit motor type, DSV5445 type).
The system BERIPAC with BERIPACK.KOM is pre-set completely. The factory settings for BERIPAC are in
brackets, e.g. F0 (750).
