EMOTRON DSV 5445/5444
Page 42
Emotron 21.04.09
Adr. Variable in FU-Control Remarks TUDY/X TUDZ
E4E Starting jerk time
V Time needed to overcome static friction. If rollers are
employed, the value can be set below 100 ms. In the
case of slide ways, the value can be 1000 ms (with
simultaneous back-pack suspension, the time can lie
over 1.5 s, whereby the starting jerk speed is then
0.003 to 0.005). Value range typically: 1 - 2500 ms
Only for 7TZ-progr. with analogue setpoint setting:
Value for tolerance-time for identifying setpoint = 0.
250 125
E50 Findili flag / Binary flag
V 7TZ-based programs with ‘index-95’ (or higher) could
be switched with flag ‘0E50’ from ‘normal’ input-mode
to ‘binary’ input-mode. Customisation of those lift-
programs to STEP controller and similar controls with
binary coded specification of speeds and bidirectional
signals is only available with firmware ≥ date July ’05!
Other program- and index-versions have only the
older function ‘V3=V1+V2’, if flag 0E50 is set to ‘255’ !
Newest version of programs selected between 'KEB'
or 'CT'-coded binary inputs (0E50h = 255 or set -256)!
Firmware > end of 2008 also have the possibility to
set the value 0E50 to 15 for half-decimal coded plc’s.
0 0
E52 speed-filter all
V The actual value of the encoder is filtered:
E52 = 0 without, 255 medium, -256 high filtering.
Control is stiffer at 0, however slight noises occur,
depending upon the quality of the encoder signal.
255 255
E54 current-filter all
V The torque output is filtered:
E52 = 0 without, 255 medium, -256 high filtering.
Control is stiffer at 0, however loud noises occur,
depending upon the quality of the encoder signal.
255 255
E56 64_256_switch 50 MHz
V Only readable flag: It shows whether multiplication =
'256' (255) or ’512’ (-256) or ’64/16’ (0)
0 255
E58 no reset on error
V For '0', the inverter is automatically reset after a fault.
For '255', it waits with all current faults for a reset.
Using firmware TUDYXXX and TUDZXXX from
February 05 (M-No. 231500) a choice concerning the
fault handling can be made.
’20’ means: all faults will be reset, except encoder
and processor faults (see Chapter 9.2.1)
20 (new)
255 (old)
23 (new)
255 (old)
E5A value of iidt-timer
V Unacceptable high current, incorrect rotating fields
and phase angle, and loose encoder lead to a shut-
down of the inverter after the time in E5A (I²dt error
has occurred).
5000 2500
E5C search RHO ATB-gearl.
V
This variable starts the 'first initialisation' of a new
synchronous motor (for example after changing an
encoder). Note: Before set this value from '0' to '255'
be sure to have a 'high'-signal on input 'ISP' (X1 pin 5)
and opened the breaks and closed all contactors. For
more details see PowerPoint-file on the EmoSoftLift-
CD.
0 0
E5E Rho_Shift Synchronm.
V
Only important for synchronous motors ('50 MHz')
The angular displacement RHO changes with
increasing speed, preset in the factory according to
motor type.
7...21 7...84
