11.2.1.6 Bus system settings
see also parameter and variables list
Controldelieverer Newlift bp bp Kollmorgen Kollmorgen
Fieldbus ACP_03 DCP_03 DCP_04 DCP_03 DCP_04
0E64 (DCP, ACP, CAN) 87 92 93 172 173
0E66 (baudrate) 6 2 2 2 2
0E0C (direction of rotation/bus=255) 255 255 255 255 255
11.2.2 Connector position "XC" (CAN interface):
Lower connector / 9-pole male
Pin 1 = n.c. Pin 4 = n.c. Pin 7 = CAN-HIGH
Pin 2 = CAN-LOW Pin 5 = Earth Pin 8 = n.c.
Pin 3 = GND Pin 6 = n.c. Pin 9 = n.c.
Transferring a standard program for conventional activation based on *7TZ.KOM via
EmoSoftLift the field bus functions will be deactivated even if the option card is mounted.
11.3 Option IT-net
The DSV 5445 series size 1-4 can be provided with option IT-net. This option contains a special RFI
suppression filter, so that operation in case of also earth fault, i.e. one of the phases is short-circuited with
the insulated protective earth, is possible unlimited.
The specification resp. measuring of the radio interference level refers to a none insulated
protective earth system.
The earth fault monitoring has to tolerate the earth leakage current caused by the systems
principle, these are the RFI suppression capacitors and the capacity of the motor.
Use an applicable line filter.
DSV 5445 with option IT-net are also suitable for operation in TN-, TT-net. A special radio
interference level can not be specified here.
The control voltages of the lift system have to be prepared potential-free. Pay attention to the
instructions of the operator.
