User Manual
Chapter 3. Commands for RIP 44
www.qtech.ru
Gateway Distance Last Update Bad Packets Bad Routes
20.1.1.1 120 00:00:31 0 0
Distance: (default is 120)
Displayed information
Explanation
Sending updates every 30 seconds with +/-50%, next
due in 8 seconds
Sending update every 30
secs
Timeout after 180 seconds, garbage collect after 120
seconds
The route time-out event
period is 180 secs, the
garbage collect time is 120
seconds
Outgoing update filter list for all interface is not set
Outgoing update filter list
for all interface is not set
Incoming update filter list for all interface is not set
Incoming update filter list
for all interface is not set
Default redistribution metric is 1
Default redistribution metric
is 1
Redistributing: static
Redistributing the static
route into the RIP route
Default version control: send version 2, receive
version 2
Interface Send Recv Key-chain
Ethernet1/0/3 2 2
The configuration of
interface receiving and
sending packets. Receive
version is 2, keychain 1 not
configured.
Routing for Networks:
Vlan1
Vlan2
The segment running RIP is
the Vlan 1 and Vlan 2
Routing Information Sources:
Gateway Distance Last Update Bad Packets Bad
Routes
20.1.1.1 120 00:00:31 0 0
Routing information sources
The badpacketand bad
routes from the gateway
20.1.1.1 are all 0. 31
seconds have passed since
