AVH-P7800DVD/UC
199
5678
56
7
8
C
D
F
A
B
E
It is the thing of the check after connection to a jig etc. about 24Pin FFC.
No.
Rated value 1
VCC33V - 0.6 V or
over
6
Side A
Fig.11.6 : Digital audio signal(IECOUT) check point
CN1851
ADOUT0/SUBC
ADOUT1/BLKCK
ADOUT2/CLDCK
SRCK
LRCK
DATA
MCKENA
RIPP
SBCK
BMUTE
EMPH
IEC/IPFLG
IC1501
LSI
IC1851 buffer SW
Ripping or
6 ch digtal out
IC1852 buffer SW
Ripping or
6 ch digtal out
IC1853 buffer SW
Ripping or
6 ch digtal out
pin14
CN1851
IC1851
DGND2
It checks on the basis of DGND.
Verification location 1
(Sensing pin)
IEC
Verification
location 2
CN1851 pin14
Rated value 2
0.4 V or lower
Reference
waveform
Waveform 5
The six serial signals, output from the DVD-LSI(IC1501), are output from the CN1851 at the time of 6 ch digtal out.
The three serial.digital signal and SUBC, output from the DVD-LSI(IC1501),
are output by 4 X from the CN1851 at the ripping.
