LEAVING WATER
CONDENSER
20 25 30 35
LWE
MODEL
CC HC PI CC HC PI CC HC PI CC HC PI
4 5 13.6 16.4 2.83 13.2 16.2 3.08 12.7 15.9 3.37 12.0 15.7 3.71
8 21.8 25.9 4.23 21.3 25.8 4.70 20.6 25.7 5.23 19.8 25.5 5.80
10 26.7 32.2 5.72 26.7 32.8 6.26 26.4 33.1 6.91 25.7 33.2 7.69
12 30.8 37.3 6.69 30.7 37.9 7.35 30.6 38.4 8.12 30.0 38.7 8.97
16 43.6 51.9 8.62 42.5 51.8 9.57 41.1 51.5 10.6 39.5 51.1 11.8
20 53.5 64.9 11.9 53.5 66.0 13.0 52.8 66.6 14.3 51.5 66.9 15.9
24 61.6 74.9 13.5 61.5 76.0 14.8 61.1 77.0 16.3 59.9 77.5 18.0
32 87 104 17.2 85 104 19.1 82 103 21.2 79 102 23.6
36 97 117 20.5 96 118 22.6 94 118 24.9 91 118 27.7
40 107 130 23.8 107 132 26.0 106 133 28.6 103 134 31.8
44 115 140 25.4 115 142 27.8 114 144 30.6 111 144 33.9
48 123 150 27.0 123 152 29.6 122 154 32.7 120 155 36.1
52 141 169 29 138 169 32 135 170 36 131 169 39
56 151 182 32.5 149 184 35.6 147 185 39.2 143 185 43.5
60 160 195 35.8 160 198 39.0 159 200 42.9 155 201 47.6
64 169 205 37.3 168 208 40.8 167 210 45.0 163 211 49.8
68 177 215 38.9 176 218 42.6 175 221 47.0 171 222 51.9
72 185 225 40.4 184 228 44.4 183 231 49.0 180 233 54.1
7 5 14.9 17.7 2.89 14.3 17.3 3.12 13.7 16.9 3.39 13.0 16.6 3.71
8 23.3 27.5 4.43 23.0 27.6 4.85 22.4 27.6 5.35 21.5 27.3 5.96
10 28.9 34.5 5.81 28.9 35.0 6.37 28.6 35.4 7.03 28.0 35.5 7.76
12 33.1 39.7 6.83 33.0 40.2 7.51 33.0 40.9 8.27 32.5 41.3 9.10
16 46.4 55.1 9.02 45.9 55.4 9.87 44.7 55.3 10.9 43.0 54.8 12.1
20 57.9 69.4 12.1 57.9 70.5 13.2 57.3 71.2 14.5 56.0 71.4 16.0
24 66.2 79.4 13.8 66.1 80.5 15.1 65.9 82.0 16.6 65.0 82.7 18.3
32 93 110 18.0 92 111 19.7 89 111 21.7 86 110 24.2
36 104 124 21.1 104 126 23.1 102 127 25.4 99 126 28.1
40 116 139 24.2 116 141 26.5 115 142 29.1 112 143 32.0
44 124 149 25.9 124 151 28.3 123 153 31.2 121 154 34.3
48 132 159 27.5 132 161 30.2 132 164 33.3 130 165 36.6
52 151 180 30.2 150 181 33.0 147 182 36.3 142 181 40.2
56 162 194 33.2 162 196 36.3 159 198 40.0 155 198 44.1
60 174 208 36.3 174 212 39.7 172 214 43.6 168 214 48.0
64 182 218 38.0 182 222 41.6 181 225 45.7 177 226 50.3
68 190 228 39.6 190 232 43.5 189 235 47.8 186 237 52.6
72 199 238 41.3 198 242 45.3 198 246 49.9 195 248 54.9
10 5 15.5 18.2 2.90 15.1 18.1 3.16 14.8 18.1 3.46 14.3 17.9 3.76
8 24.6 28.8 4.44 24.4 29.1 4.89 24.0 29.2 5.41 23.3 29.1 5.98
10 30.4 35.9 5.85 30.3 36.5 6.42 30.1 36.9 7.08 29.6 37.2 7.83
12 34.5 41.1 6.96 34.4 41.7 7.64 34.3 42.3 8.41 33.7 42.6 9.26
16 49.1 57.8 9.05 48.7 58.3 10.0 47.9 58.5 11.0 46.6 58.3 12.1
20 60.9 72.4 12.2 60.7 73.4 13.3 60.3 74.3 14.6 59.4 74.8 16.1
24 69.0 84.1 14.0 68.9 85.2 15.4 68.5 86.5 16.9 67.5 87.1 18.6
32 98 116 18.1 97 117 19.9 96 117 22.0 93 117 24.3
36 110 130 21.2 109 132 23.3 108 133 25.6 106 133 28.3
40 122 145 24.4 121 147 26.6 121 149 29.3 119 150 32.3
44 130 156 26.2 130 159 28.7 129 161 31.6 127 162 34.8
48 138 168 28.0 138 170 30.8 137 173 33.9 135 174 37.2
52 156 185 30.2 155 187 33.2 153 188 36.5 149 188 40.3
56 171 202 33.4 170 205 36.6 169 207 40.3 165 208 44.4
60 183 217 36.6 182 220 40.0 181 223 43.9 178 225 48.4
64 191 229 38.4 190 232 42.0 189 235 46.2 186 237 50.9
68 199 241 40.2 198 244 44.1 197 247 48.5 194 249 53.4
72 207 252 42.1 207 256 46.2 206 259 50.8 202 261 55.8
4TW53472-1D 4TW53472-2B
4TW53472-3B 4TW53472-4B
SYMBOLS
CC : Cooling capacity (kW)
HC : Heating capacity (kW)
PI : Power input (kW)
LWE : Leaving Water Evaporator (°C)
NOTES
1 Cooling capacity (CC)
CAP = Cooling capacity from table (kW)
Capacity is for chilled water range Dt = 2∼5°C
2 Power input (PI)
PI = Power input from table (kW)
Power input is total input kW: compressor + control circuit + pumps (kW)
3 Water flow rate (WFR)
WFR = (860 x CC)/(60 x Dt) (l/min)
CC = From above calculation
Dt = Chilled water temperature rise within 2-5°C
WFR should always be within the limits
4 No pumps are supplied with the unit, so the added power input for the pumps is calculated
as (WFR m
3
/s x DPa) m
3
/s /0.3 as fixed by 6/C/003 (Dp = pressure drop from pressure drop
curves).
This is for cooled and cooling water.
Shows nominal cooling capacities and power input
•
Water-cooled • R-407C • EUW5-24KZW
4
Capacity tables
4-1
Cooling / heating capacities
1
4
4-1
13
• Applied Systems • Chillers
