Daikin EUW10KZW [7/49] Specifications
![Daikin EUW10KZW [7/49] Specifications](/views2/1669388/page7/bg7.png)
3
Specifications
NOMINAL CAPACITY, CAPACITY STEPS and NOMINAL INPUT
UNITS EUW5KZW EUW8KZW EUW10KZW EUW12KZW EUW16KZW
NOMINAL CAPACITY Cooling kW 13.0 21.5 28.0 32.5 43.0
CAPACITY STEPS 11112
NOMINAL INPUT Cooling kW 3.71 5.96 7.76 9.10 12.1
EER 3.50 3.61 3.61 3.57 3.55
TECHNICAL SPECIFICATIONS
UNITS EUW5KZW EUW8KZW EUW10KZW EUW12KZW EUW16KZW
DIMENSIONS Unit H mm 600 600
W mm 600 600
D mm 600 1,200
WEIGHT Machine weight kg 113 150 160 167 300
MATERIAL Polyester painted steel plate
COLOUR Ivory white / Munsell code 5Y7.5/1
SOUND LEVEL Sound pressure dBA −−−−−
Sound power dBA 64 64 64 71 67
EVAPORATOR Type Brased plate heat exchanger
Qty 11111
Minimum water volume in the system l 62 103 134 155 205
Nominal water flow l/min 37 62 80 93 123
Water flow rate (min/max) l/min 19/75 31/123 40/161 47/186 62/247
Insulation material Polyethylene foam
CONDENSER Type Brased plate heat exchanger
Qty 11111
Nominal water flow l/min 48 78 102 118 157
Water flow rate (min/max) l/min 24/95 39/157 51/203 59/237 79/314
REFRIGERANT CIRCUIT Refrigerant type R-407C
Refrigerant charge kg 1.2 2 2.3 2.7 4.6
No. of circuits 11112
Refrigerant control Thermostatic expansion valve
COMPRESSOR Type Hermetically sealed scroll
Qty x model 1xJT140BF-YE 1xJT212DA-YE 1xJT300DA-YE 1xJT335DA-YE 2xJT212DA-YE
No. of compressors 11112
Speed rpm 2,900 2,900 2,900 2,900 2,900
Refrigerant oil type FVC68D
Refrigerant oil charge l 1.5 2.7 2.7 2.7 2 x 2.7
PIPING CONNECTIONS Evap. water in/outlet mm FBSP 25 FBSP 40
Condenser water in/outlet mm FBSP 25 FBSP 40
Evaporator water drain Field installation
Relief device outlet Field installation
Filter strainer Field installation
Flow switch Field installation
SAFETY DEVICES High pressure switch / Low pressure switch / Freeze-up protection / Reverse phase protector / Discharge temperature protection /
Compressor motor overcurrent / Anti recycling timer / Guard timer
4TW53471-1D
•
Water-cooled • R-407C • EUW5-24KZW
1
3
5
• Applied Systems • Chillers
