LEAVING WATER
CONDENSER
40 45 50 55
LWE
MODEL
CC HC PI CC HC PI CC HC PI CC HC PI
4 5 11.4 15.4 4.04 10.7 15.1 4.43 10.0 14.8 4.85 9.1 14.4 5.34
8 18.8 25.1 6.44 17.7 24.7 7.12 16.4 24.2 7.86 15.1 23.7 8.65
10 24.9 33.2 8.48 23.7 32.9 9.40 22.2 32.5 10.41 20.3 31.8 11.61
12 28.9 38.7 9.95 27.5 38.3 11.03 25.6 37.7 12.20 23.4 36.7 13.45
16 37.5 50.3 13.0 35.2 49.5 14.4 32.7 48.4 15.9 30.1 47.4 17.5
20 49.8 66.8 17.4 47.5 66.3 19.3 44.5 65.4 21.3 40.7 64.0 23.7
24 57.9 77.4 20.0 55.0 76.6 22.2 51.3 75.2 24.5 46.9 73.3 27.0
32 75 101 26.1 70 99 28.8 65 97 31.8 60 95 34.9
36 87 117 30.5 83 116 33.7 77 114 37.2 71 111 41.2
40 100 134 34.9 95 133 38.6 89 131 42.6 81 128 47.4
44 108 144 37.5 102 143 41.4 96 141 45.8 88 137 50.7
48 116 155 40.0 110 153 44.3 103 150 49.0 94 147 54.0
52 125 167 44 118 165 48 110 162 53 101 159 59
56 137 184 47.9 130 182 53.0 122 179 58.5 112 176 64.9
60 150 200 52.3 142 199 57.9 134 196 63.9 122 192 71.1
64 158 211 54.9 150 209 60.7 140 206 67.1 128 201 74.4
68 166 222 57.5 157 220 63.6 147 216 70.3 134 211 77.7
72 174 232 60.0 165 230 66.5 154 226 73.5 141 220 81.0
7 5 12.3 16.3 4.07 11.6 16.0 4.47 10.9 15.7 4.91 10.1 15.4 5.39
8 20.5 26.9 6.50 19.2 26.2 7.16 17.6 25.4 7.87 15.6 24.3 8.78
10 27.1 35.5 8.60 26.0 35.3 9.52 24.5 34.9 10.53 22.6 34.1 11.63
12 31.5 41.4 10.12 30.1 41.0 11.19 28.1 40.3 12.38 25.7 39.0 13.55
16 40.9 53.9 13.2 38.3 52.5 14.5 35.1 50.8 15.9 31.1 48.7 17.7
20 54.4 71.5 17.7 52.0 71.0 19.5 49.1 70.2 21.6 45.3 68.6 23.7
24 63.1 82.8 20.3 60.2 82.0 22.5 56.3 80.4 24.9 51.3 77.9 27.2
32 82 108 26.4 77 105 29.0 70 102 31.8 62 97 35.5
36 95 125 30.9 90 124 34.0 84 121 37.5 76 117 41.4
40 109 143 35.4 104 142 39.1 98 140 43.1 91 137 47.3
44 117 154 38.0 112 153 42.0 105 151 46.4 97 146 50.9
48 126 166 40.7 120 164 45.0 113 161 49.7 103 156 54.4
52 136 179 44.0 129 176 48.5 119 172 53.4 108 166 59.1
56 150 197 48.6 142 195 53.6 133 191 59.0 122 186 65.1
60 163 214 53.1 156 213 58.6 147 210 64.7 136 206 71.0
64 172 226 55.7 164 224 61.5 154 221 68.0 142 215 74.5
68 181 237 58.4 172 235 64.5 162 231 71.3 148 224 78.1
72 189 248 61.0 180 246 67.5 169 241 74.6 154 234 81.6
10 5 13.7 17.8 4.16 13.0 17.5 4.57 12.2 17.2 5.01 11.2 16.6 5.43
8 22.3 28.8 6.59 21.1 28.2 7.27 19.5 27.3 8.00 17.6 26.3 8.81
10 29.0 37.4 8.65 27.9 37.3 9.57 26.6 37.0 10.58 24.9 36.3 11.70
12 32.8 42.7 10.24 31.4 42.4 11.29 29.6 41.8 12.44 27.5 40.9 13.63
16 44.6 57.6 13.4 42.0 56.5 14.7 38.9 54.8 16.2 35.1 52.7 17.8
20 58.0 75.2 17.8 56.0 75.0 19.6 53.3 74.4 21.6 49.8 73.1 23.9
24 65.5 87.1 20.6 62.8 86.5 22.7 59.3 85.2 25.0 55.0 83.3 27.4
32 89 115 26.7 84 113 29.4 78 110 32.4 70 105 35.6
36 103 133 31.2 98 131 34.3 92 129 37.8 85 126 41.7
40 116 150 35.6 112 150 39.3 107 149 43.3 100 146 47.8
44 124 162 38.4 119 161 42.3 113 160 46.6 105 156 51.2
48 131 174 41.1 126 173 45.4 119 170 49.9 110 167 54.7
52 144 187 44.4 136 184 49.0 127 180 53.9 115 174 59.3
56 161 208 48.9 154 206 54.0 146 204 59.5 135 199 65.6
60 174 226 53.4 168 225 58.9 160 223 64.9 149 219 71.7
64 182 237 56.2 175 236 61.9 166 234 68.3 155 230 75.1
68 189 249 58.9 182 248 65.0 172 245 71.6 160 240 78.6
72 197 261 61.7 188 259 68.0 178 256 74.9 165 250 82.1
4TW53472-1D 4TW53472-2B
4TW53472-3B 4TW53472-4B
SYMBOLS
CC : Cooling capacity (kW)
HC : Heating capacity (kW)
PI : Power input (kW)
LWE : Leaving Water Evaporator (°C)
NOTES
1 Cooling capacity (CC)
CAP = Cooling capacity from table (kW)
Capacity is for chilled water range Dt = 2∼5°C
2 Power input (PI)
PI = Power input from table (kW)
Power input is total input kW: compressor + control circuit + pumps (kW)
3 Water flow rate (WFR)
WFR = (860 x CC)/(60 x Dt) (l/min)
CC = From above calculation
Dt = Chilled water temperature rise within 2-5°C
WFR should always be within the limits
4 No pumps are supplied with the unit, so the added power input for the pumps is
calculated as (WFR m
3
/s x DPa) m
3
/s /0.3 as fixed by 6/C/003 (Dp = pressure drop
from pressure drop curves).
This is for cooled and cooling water.
•
Water-cooled • R-407C • EUW5-24KZW
4
Capacity tables
4-1
Cooling / heating capacities
1
4
4-1
14
• Applied Systems • Chillers
