LEAVING WATER
CONDENSER
20 25 30 35
LWE
MODEL
CC HC PI CC HC PI CC HC PI CC HC PI
14 5 16.2 19 2.91 16.2 19.2 3.22 16.2 19.6 3.54 16 19.7 3.84
8 26.4 30.6 4.46 26.3 31 4.95 26.2 31.4 5.48 25.7 31.5 6.01
10 32.3 37.9 5.91 32.2 38.4 6.48 32.2 39 7.14 31.9 39.5 7.92
12 38.4 45 7.14 38.3 45.7 7.82 38 46.1 8.6 37.4 46.4 9.47
16 52.6 61.3 9.1 52.5 62.1 10.1 52.2 62.9 11.1 51.3 63.1 12.2
20 64.7 76.2 12.3 64.5 77.2 13.4 64.4 78.4 14.8 63.9 79.4 16.3
24 76.8 90.3 14.4 76.7 91.6 15.7 76 92.4 17.3 74.9 93 19
32 105 123 18.2 105 124 20.2 104 126 22.3 103 126 24.4
36 117 137 21.4 117 139 23.5 117 141 25.9 115 142 28.5
40 129 152 24.6 129 154 26.9 129 157 29.5 128 159 32.6
44 141 167 26.7 141 169 29.2 140 171 32.1 139 172 35.4
48 154 181 28.7 153 183 31.5 152 185 34.6 150 186 38.1
52 170 199 30.5 170 201 33.6 169 204 37 167 206 40.7
56 182 214 33.7 182 216 37 181 220 40.7 179 222 44.8
60 194 229 36.9 194 232 40.3 193 235 44.3 192 238 49
64 206 243 39 206 246 42.6 205 249 46.8 203 252 51.7
68 218 257 41 218 260 44.9 216 263 49.4 214 265 54.4
72 230 271 43.1 230 275 47.2 228 277 51.9 225 279 57.1
16 5 16.7 19.5 2.92 16.7 19.7 3.23 16.7 20 3.56 16.5 20.2 3.86
8 27.2 31.4 4.47 27.1 31.8 4.96 27 32.2 5.49 26.6 32.4 6.03
10 32.6 38.2 5.92 32.6 38.7 6.51 32.5 39.3 7.19 32.3 39.9 7.95
12 38.8 45.5 7.19 38.7 46.1 7.88 38.5 46.6 8.67 38.1 47.1 9.56
16 54.3 62.9 9.12 54.2 63.8 10.1 54 64.6 11.2 53.2 64.9 12.2
20 65.3 76.8 12.3 65.2 77.9 13.5 65.1 79.1 14.9 64.7 80.3 16.4
24 77.7 93 14.5 77.5 94.2 15.9 77 95.2 17.4 76.2 96.1 19.2
32 109 126 18.2 108 128 20.2 108 129 22.3 106 130 24.5
36 120 140 21.5 119 142 23.6 119 144 26 118 145 28.6
40 131 154 24.7 130 156 27 130 158 29.7 129 161 32.8
44 143 170 26.8 143 172 29.4 142 174 32.3 141 176 35.6
48 155 186 28.9 155 188 31.7 154 190 34.9 152 192 38.4
52 174 203 30.6 174 205 33.7 173 208 37.2 171 210 40.9
56 185 217 33.8 185 219 37.1 184 223 40.9 183 225 45
60 196 231 37 196 234 40.5 195 237 44.6 194 241 49.2
64 208 247 39.1 208 250 42.9 207 253 47.2 206 257 52
68 221 263 41.3 220 266 45.2 219 269 49.7 217 272 54.8
72 233 279 43.4 232 283 47.6 231 286 52.3 228 288 57.7
20 5 17.6 20.4 2.93 17.6 20.6 3.25 17.5 20.9 3.59 17.5 21.2 3.9
8 28.9 33 4.5 28.8 33.5 4.99 28.7 33.9 5.52 28.5 34.2 6.06
10 33.2 38.8 5.96 33.2 39.4 6.58 33.1 40 7.27 33.1 40.8 8.03
12 42.2 49 7.29 42.2 49.6 8 42.1 50.3 8.81 42 51.2 9.74
16 57.6 66.2 9.17 57.5 67 10.1 57.4 68 11.2 56.9 68.5 12.3
20 66.6 78.1 12.4 66.5 79.3 13.6 66.4 80.5 15 66.4 82 16.6
24 84.5 98.2 14.7 84.4 99.5 16.1 84.2 101 17.7 84 102 19.6
32 115 132 18.3 115 134 20.3 115 136 22.4 114 137 24.6
36 124 144 21.6 124 146 23.8 124 149 26.2 123 151 28.8
40 133 156 24.8 133 159 27.3 133 161 30.1 133 164 33.1
44 151 176 27.1 151 179 29.7 151 181 32.7 150 184 36.1
48 169 196 29.4 169 199 32.2 168 201 35.4 168 205 39.2
52 182 211 30.7 182 213 33.9 181 216 37.4 180 219 41.1
56 191 222 34 191 226 37.4 190 229 41.3 190 233 45.4
60 200 234 37.2 200 238 40.9 199 242 45.1 199 246 49.7
64 218 254 39.5 217 258 43.4 217 262 47.8 217 266 52.7
68 236 275 41.8 235 278 45.9 235 282 50.5 234 287 55.7
72 253 295 44 253 298 48.3 253 302 53.1 252 307 58.8
4TW53472-1D 4TW53472-2B
4TW53472-3B 4TW53472-4B
SYMBOLS
CC : Cooling capacity (kW)
HC : Heating capacity (kW)
PI : Power input (kW)
LWE : Leaving Water Evaporator (°C)
NOTES
1 Cooling capacity (CC)
CAP = Cooling capacity from table (kW)
Capacity is for chilled water range Dt = 2∼5°C
2 Power input (PI)
PI = Power input from table (kW)
Power input is total input kW: compressor + control circuit + pumps (kW)
3 Water flow rate (WFR)
WFR = (860 x CC)/(60 x Dt) (l/min)
CC = From above calculation
Dt = Chilled water temperature rise within 2-5°C
WFR should always be within the limits
4 No pumps are supplied with the unit, so the added power input for the pumps is
calculated as (WFR m
3
/s x DPa) m
3
/s /0.3 as fixed by 6/C/003 (Dp = pressure drop
from pressure drop curves).
This is for cooled and cooling water.
•
Water-cooled • R-407C • EUW5-24KZW
4
Capacity tables
4-1
Cooling / heating capacities
1
4
4-1
15
