LEAVING WATER
CONDENSER
40 45 50 55
LWE
MODEL
CC HC PI CC HC PI CC HC PI CC HC PI
14 5 15.6 19.7 4.28 14.9 19.5 4.70 14.0 19.0 5.15 12.8 18.2 5.48
8 24.8 31.3 6.71 23.6 30.8 7.42 22.0 30.0 8.18 20.2 28.9 8.86
10 31.4 39.8 8.72 30.6 39.9 9.64 29.4 39.8 10.64 27.9 39.4 11.79
12 36.5 46.4 10.39 35.2 46.2 11.41 33.7 45.9 12.52 32.0 45.4 13.74
16 49.5 62.6 13.6 47.1 61.7 15.0 43.9 60.1 16.5 40.3 57.9 17.9
20 62.9 80.1 17.9 61.3 80.3 19.8 59.0 80.0 21.8 55.8 79.2 24.1
24 72.9 92.8 20.9 70.5 92.4 22.9 67.4 91.6 25.1 64.0 90.6 27.6
32 99 125 27.2 94 123 30.0 88 120 33.1 81 116 35.8
36 112 143 31.5 108 142 34.8 103 140 38.3 96 137 42.0
40 126 160 35.9 123 161 39.5 118 160 43.5 112 158 48.1
44 136 173 38.8 132 173 42.7 126 172 46.9 120 170 51.6
48 146 186 41.8 141 185 45.9 135 183 50.3 128 181 55.1
52 162 205 45.1 155 204 49.8 147 200 54.8 136 195 59.8
56 175 223 49.5 170 222 54.6 162 220 60.1 152 216 66.0
60 189 240 53.8 184 241 59.3 177 240 65.3 167 238 72.2
64 199 253 56.8 193 253 62.5 185 252 68.7 176 249 75.7
68 209 266 59.7 202 265 65.6 194 263 72.0 184 260 79.2
72 219 279 62.7 211 277 68.8 202 275 75.4 192 272 82.7
16 5 16.2 20.3 4.30 15.6 20.2 4.72 14.8 19.8 5.16 13.7 19.0 5.50
8 25.8 32.3 6.73 24.7 31.9 7.43 23.2 31.2 8.19 21.5 30.2 8.88
10 31.9 40.3 8.78 31.2 40.6 9.70 30.2 40.6 10.71 28.9 40.4 11.82
12 37.3 47.3 10.47 36.1 47.2 11.49 34.7 46.9 12.59 32.9 46.4 13.84
16 51.6 64.7 13.6 49.4 63.9 15.0 46.4 62.6 16.6 42.8 60.4 17.9
20 63.9 81.1 18.1 62.5 81.6 19.9 60.5 81.6 21.9 57.9 81.3 24.1
24 74.5 96.3 21.0 72.3 96.1 23.1 69.3 95.3 25.3 65.9 94.4 27.8
32 103 129 27.3 99 128 30.1 93 125 33.1 86 121 35.9
36 116 146 31.7 112 146 34.9 107 144 38.5 101 142 42.1
40 128 162 36.1 125 163 39.8 121 163 43.8 116 163 48.3
44 138 177 39.1 135 178 43.0 130 177 47.2 124 176 51.9
48 149 193 42.1 145 192 46.2 139 191 50.6 132 189 55.5
52 167 211 45.3 161 209 50.0 153 207 55.0 144 202 60.0
56 179 227 49.7 174 227 54.8 167 226 60.4 159 223 66.2
60 192 243 54.2 187 245 59.7 182 245 65.7 174 244 72.4
64 202 259 57.2 197 259 62.9 190 259 69.1 182 257 76.0
68 213 274 60.1 207 274 66.1 199 272 72.5 190 270 79.7
72 224 289 63.1 217 288 69.3 208 286 75.8 198 283 83.3
20 5 17.4 21.5 4.33 17.0 21.5 4.75 16.3 21.3 5.19 15.4 20.7 5.53
8 28.0 34.4 6.75 27.0 34.2 7.46 25.8 33.7 8.22 24.0 32.7 8.93
10 32.9 41.4 8.90 32.4 41.9 9.83 31.8 42.2 10.84 31.0 42.5 11.89
12 41.5 51.6 10.63 40.6 51.7 11.65 39.2 51.4 12.74 37.4 51.0 14.04
16 55.8 68.9 13.7 54.0 68.5 15.1 51.4 67.5 16.6 47.9 65.4 18.0
20 65.9 83.3 18.3 65.0 84.2 20.1 63.7 84.9 22.2 62.1 85.4 24.3
24 83.0 103 21.4 81.2 103 23.4 78.4 103 25.6 74.9 102 28.2
32 112 138 27.4 108 137 30.2 103 135 33.2 96 131 36.1
36 122 152 32.0 119 153 35.2 115 152 38.8 110 151 42.3
40 132 167 36.6 130 168 40.3 127 170 44.3 124 171 48.6
44 149 186 39.6 146 188 43.5 142 188 47.7 137 187 52.5
48 166 206 42.7 162 207 46.8 157 205 51.1 150 203 56.4
52 178 221 45.6 173 221 50.3 167 220 55.4 158 216 60.3
56 188 235 50.2 184 237 55.4 179 237 60.9 172 236 66.6
60 198 250 54.8 195 253 60.4 191 255 66.5 186 256 72.8
64 215 270 57.9 211 272 63.7 206 273 69.9 199 273 76.7
68 232 290 61.0 227 291 66.9 220 290 73.3 212 289 80.6
72 249 309 64.1 244 310 70.2 235 308 76.7 225 305 84.5
4TW53472-1D 4TW53472-2B
4TW53472-3B 4TW53472-4B
SYMBOLS
CC : Cooling capacity (kW)
HC : Heating capacity (kW)
PI : Power input (kW)
LWE : Leaving Water Evaporator (°C)
NOTES
1 Cooling capacity (CC)
CAP = Cooling capacity from table (kW)
Capacity is for chilled water range Dt = 2∼5°C
2 Power input (PI)
PI = Power input from table (kW)
Power input is total input kW: compressor + control circuit + pumps (kW)
3 Water flow rate (WFR)
WFR = (860 x CC)/(60 x Dt) (l/min)
CC = From above calculation
Dt = Chilled water temperature rise within 2-5°C
WFR should always be within the limits
4 No pumps are supplied with the unit, so the added power input for the pumps is
calculated as (WFR m
3
/s x DPa) m
3
/s /0.3 as fixed by 6/C/003 (Dp = pressure drop
from pressure drop curves).
This is for cooled and cooling water.
•
Water-cooled • R-407C • EUW5-24KZW
4
Capacity tables
4-1
Cooling / heating capacities
1
4
4-1
16
• Applied Systems • Chillers
