* If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below

for connection details in accordance with the type of speaker you use.

Audio Output

Channels

Front Speaker

(No. 5)

Rear Speaker

(No. 3)

Central / Bass

(No. 2)

Line In

(No. 4)

2 V -- -- --

4 V V -- --

6 V V V --

8 V V V V

**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange

100Mbps/1Gbps

connection

On Link Green 2.5Gbps connection

*** ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

**** ACPI wake-up function is not supported on USB3_4

5 ports.

ACT/LINK LED

SPEED LED

LAN Port

ACT/LINK LED

SPEED LED

LAN Port
