Basic Control Si34-704
98 Function
2.3 Electronic Expansion Valve PI Control
Main Motorized Valve EV1 Control
Fixed to open fully.
Subcooling Motorized Valve EV2 Control
Makes PI control of the motorized valve (Y2E) to keep the superheated degree of the outlet gas
pipe on the evaporator side for the full use of the subcooling heat exchanger.
2.4 Step Control of Outdoor Unit Fans
Used to control the revolutions of outdoor unit fans in the steps listed in table below, according to condition changes.
* Figures listed above are all those controlled while in standard mode, which vary when the system is set to high static
pressure or capacity precedence mode.
2.5 Outdoor Unit Fan Control in Cooling Operation
While in cooling operation, if the outdoor temperature is low, this mode provides high-pressure
control using the outdoor unit fan to retain appropriate liquid pressure, thus ensuring refrigerant
circulation rate to be supplied to indoor units.
SH = Tsh -Te SH : Outlet superheated degree of evaporator (°C)
Tsh : Suction pipe temperature detected with the
thermistor R5T (°C)
Te : Low pressure equivalent saturation
temperature (°C)
STEP
No.
Fan revolutions (rpm)
RXQ5P RXQ8P RXQ10P
RXQ12P
(Europe)
RXQ12P
(except Europe)
RXQ14P
RXQ16P RXQ18P
FAN1 FAN2 FAN1 FAN2 FAN1 FAN2
0 0 0 0 0 000000
1 285 350 350 350 230 0 230 0 395 0
2 315 370 370 370 380 0 380 0 460 0
3 360 400 400 400 290 260 290 260 570 0
4 450 450 460 460 375 345 375 345 385 355
5 570 540 560 560 570 540 570 540 550 520
6 710 670 680 680 720 690 720 690 800 770
7 951 760 821 870 1091 1061 1091 1061 1136 1106
8 951 796 821 870 1136 1106 1136 1106 1166 1136
Upper limit of fan
revolutions: Step 8
Upper limit of outdoor unit
fan revolutions
Step 7
-1 step on
outdoor unit fan
+1 step on
outdoor unit fan
Pc
<
2.75MPa
PI control
Pc
>
3.24MPa
Lapse of 20 sec.
PI control
PI control
*For fan revolutions in each step,
refer to information as above.
Lapse of 20 sec.
Hold the
current step on
outdoor unit fan
